SRP6540-470M

Active

Bourns Inc.

SURFACE MOUNT POWER INDUCTOR, SRP6540 SERIES, 47 H, 20%, SHIELDED, 0.366 OHM, 1.6 A ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Bourns Inc.

SURFACE MOUNT POWER INDUCTOR, SRP6540 SERIES, 47 H, 20%, SHIELDED, 0.366 OHM, 1.6 A ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Part	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Type	DC Resistance (DCR)	Inductance	Shielding	Material - Core	Package / Case	Current Rating (Amps)	Tolerance	Current - Saturation (Isat)	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Inductance Frequency - Test	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	DC Resistance (DCR) [Max]
Bourns Inc. SRP6540-100M	-55 °C	125 °C	Surface Mount	Drum Core Wirewound	78.5 mOhm	10 µH	Shielded	Iron Powder	Nonstandard	4 A	20 %	4 A	0.283 in	0.256 in	6.5 mm	7.2 mm	100 kHz	0.157 in	4 mm
Bourns Inc. SRP6540-1R0M	-55 °C	125 °C	Surface Mount	Drum Core Wirewound		1 µH	Shielded	Iron Powder	Nonstandard	12 A	20 %	13.5 A	0.283 in	0.256 in	6.5 mm	7.2 mm	100 kHz	0.157 in	4 mm	7.2 mOhm
Bourns Inc. SRP6540-470M	-55 °C	125 °C	Surface Mount	Drum Core Wirewound		47 µH	Shielded	Iron Powder	Nonstandard	1.6 A	20 %	1.6 A	0.283 in	0.256 in	6.5 mm	7.2 mm	100 kHz	0.157 in	4 mm	366 mOhm
Bourns Inc. SRP6540-8R2M	-55 °C	125 °C	Surface Mount	Drum Core Wirewound		8.2 µH	Shielded	Iron Powder	Nonstandard	4.5 A	20 %	5 A	0.283 in	0.256 in	6.5 mm	7.2 mm	100 kHz	0.157 in	4 mm	50.5 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

47 µH Shielded Drum Core, Wirewound Inductor 1.6 A 366mOhm Max Nonstandard
