CMCP300FG-08-01-00

Active

STI Vibration Monitoring

JUNCTION BOX FIBER 8"L X 6"W

Search across all available documentation for this part.

Active

STI Vibration Monitoring

JUNCTION BOX FIBER 8"L X 6"W

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Area (L x W) [custom]	Area (L x W) [custom]	Height [z]	Height [z]	Material	Ratings	Container Type	Design	Color	Area (L x W)
STI Vibration Monitoring CMCP300FG-10-01-00	8 in	254 mm	10 in	203.2 mm	80 in˛	516 cm˛	152.4 mm	6 in	Fiberglass	IP66 NEMA 4X	Junction Box	Cover Included	Gray
STI Vibration Monitoring CMCP300FG-08-01-00					47.9 in˛		101.6 mm	101.6 mm	Fiberglass	IP66 NEMA 4X	Junction Box	Cover Included	Gray	309 cm˛
STI Vibration Monitoring CMCP300FG-12-01-00	8 in	254 mm	10 in	203.2 mm	80 in˛	516 cm˛	152.4 mm	6 in	Fiberglass	IP66 NEMA 4X	Junction Box	Cover Included	Gray

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 340.00

General part information

Junction Box Fiberglass Gray Cover Included 8.000" L x 6.000" W (203.20mm x 152.40mm) X 4.000" (101.60mm)
