12RS334C

Active

Murata Power Solutions Inc.

INDUCTOR, RADIAL LEADED, 1200RS SERIES, 330 µH, 630 MA, 630 MA, 0.86 OHM, ± 15%

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Product Change Notice EN

12RS334C

Active

Murata Power Solutions Inc.

INDUCTOR, RADIAL LEADED, 1200RS SERIES, 330 µH, 630 MA, 630 MA, 0.86 OHM, ± 15%

Deep-Dive with AI

DocumentsDatasheet Product Change Notice EN

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	12RS334C

Current Rating (Amps)	0.85 A
DC Resistance (DCR) [Max]	510 mOhm
Height - Seated (Max) [Max] [z]	0.335 in
Height - Seated (Max) [Max] [z]	8.5 mm
Inductance	330 µH
Inductance Frequency - Test	10 kHz
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Vertical Cylinder, Radial
Package / Case	4 Lead
Shielding	Shielded
Size / Dimension [diameter]	10.5 mm, 0.413 in
Tolerance	15 %
Type	Wirewound

12RS Series

Part	Tolerance	Inductance	Type	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [diameter]	DC Resistance (DCR) [Max]	Inductance Frequency - Test	Shielding	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Package / Case	Current Rating (Amps)	Mounting Type	DC Resistance (DCR)
Murata Power Solutions Inc. 12RS333C	15 %	33 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	57 mOhm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	2.7 A	Through Hole
Murata Power Solutions Inc. 12RS474C	15 %		Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	980 mOhm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	0.72 A	Through Hole
Murata Power Solutions Inc. 12RS684C	15 %	680 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	1.2 Ohm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	0.55 A	Through Hole
Murata Power Solutions Inc. 12RS105C	15 %	1 mH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	1.5 Ohm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	0.44 A	Through Hole
Murata Power Solutions Inc. 12RS223C	20 %	22 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm		10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	3.3 A	Through Hole	42 mOhm
Murata Power Solutions Inc. 12RS683C	15 %	68 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	150 mOhm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	1.8 A	Through Hole
Murata Power Solutions Inc. 12RS153C	20 %	15 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	36 mOhm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	4 A	Through Hole
Murata Power Solutions Inc. 12RS154C	15 %	150 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	230 mOhm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	1.25 A	Through Hole
Murata Power Solutions Inc. 12RS103C	20 %	10 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	23 mOhm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	4.6 A	Through Hole
Murata Power Solutions Inc. 12RS334C	15 %	330 µH	Wirewound	85 °C	-40 °C	0.413 in 10.5 mm	510 mOhm	10 kHz	Shielded	0.335 in	8.5 mm	Radial Vertical Cylinder	4 Lead	0.85 A	Through Hole

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 0.85
		10	$ 0.84
		25	$ 0.83
		50	$ 0.81
		100	$ 0.77
		250	$ 0.72
		500	$ 0.67
		1000	$ 0.63
Newark	Each	250	$ 0.80

Description

General part information

12RS Series

330 µH Shielded Wirewound Inductor 850 mA 510mOhm Max Radial, Vertical Cylinder, 4 Leads
