RTM-0505S/H

Active

RECOM Power

2W DC/DC-CONVERTER ECONOLINE SMD 3KV UNREG ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

RECOM Power

2W DC/DC-CONVERTER ECONOLINE SMD 3KV UNREG ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Isolated DC/DC Converters - SMD 2W 12VIN 05VOUT 3kVDC ISO

Part	Voltage - Input (Max) [Max]	Voltage - Output 1	Power (Watts)	Applications	Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Min) [Min]	Features	Number of Outputs	Current - Output (Max) [Max]	Voltage - Isolation	Efficiency
RECOM Power RTM-0505S-R	5.5 V	5 V	2 W	ITE (Commercial) Medical	Isolated Module	90 °C	-40 °C	4.5 V	SCP	1	400 mA	2000 V	79 %
RECOM Power RTM-2405S-R	26.4 V	5 V	2 W	ITE (Commercial) Medical	Isolated Module	90 °C	-40 °C	21.6 V	SCP	1	400 mA	2000 V	83 %
RECOM Power RTM-0505S/H	5.5 V	5 V	2 W	ITE (Commercial) Medical	Isolated Module	90 °C	-40 °C	4.5 V	SCP	1	400 mA	3000 V	79 %
RECOM Power RTM-2405S/H-R	26.4 V	5 V	2 W	ITE (Commercial) Medical	Isolated Module	90 °C	-40 °C	21.6 V	SCP	1	400 mA	3000 V	83 %
RECOM Power RTM-2405S/H	26.4 V	5 V	2 W	ITE (Commercial) Medical	Isolated Module	90 °C	-40 °C	21.6 V	SCP	1	400 mA	3000 V	83 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated DC/DC Converters - SMD 2W 12VIN 05VOUT 3kVDC ISO
