BP1601-9RG
ActiveEOS Power India Private Ltd
DC/DC CONVERTER 24V 60W
Deep-Dive with AI
Search across all available documentation for this part.
BP1601-9RG
ActiveEOS Power India Private Ltd
DC/DC CONVERTER 24V 60W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BP1601-9RG |
|---|---|
| Applications | Railway, ITE (Commercial) |
| Approval Agency | cCSAus, CE, NEMKO |
| Current - Output (Max) [Max] | 2.5 A |
| Efficiency | 88 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -40 °C |
| Size / Dimension [x] | 6.46 " |
| Size / Dimension [x] | 164 mm |
| Size / Dimension [y] | 4.37 " |
| Size / Dimension [y] | 111 mm |
| Size / Dimension [z] | 0.78 in |
| Size / Dimension [z] | 19.8 mm |
| Type | Conformal Coated, Enclosed |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 16 V |
| Voltage - Isolation | 4.2 kV |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 24 | $ 1173.62 | |
Description
General part information
BP1601 Series
Enclosed, Conformal Coated DC DC Converter 1 Output 24V 2.5A 36V Input
Documents
Technical documentation and resources
No documents available
