Q-3203G000M.75M

Active

Amphenol Custom Cable

COAX CBL SMA TO SMA 29.5"

Search across all available documentation for this part.

Active

Amphenol Custom Cable

COAX CBL SMA TO SMA 29.5"

Technical Specifications

Parameters and characteristics for this part

Specification	Q-3203G000M.75M

1st Connector	SMA Jack
1st Connector Mounting Feature	Bulkhead - Front Side Nut
1st Connector Mounting Type	Panel Mount
1st Contact Gender	Female
2nd Connector	SMA Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Impedance	50 Ohms
Cable Type	LMR 240
Color	Black
Connector Impedance	50 Ohms
Features	Shielded
Frequency - Max [Max]	6000 MHz
Length	29.53 "
Length	750 mm
Overall Impedance	50 Ohms
Style	SMA to SMA

Part	1st Connector Mounting Feature	Overall Impedance	2nd Contact Gender	2nd Connector	Length	Length	Cable Impedance	Cable Type	Features	1st Connector	Color	Connector Impedance	Frequency - Max [Max]	1st Connector Mounting Type	2nd Connector Mounting Type	Style	1st Contact Gender
Amphenol Custom Cable Q-3203G000M.75M	Bulkhead - Front Side Nut	50 Ohms	Male	SMA Plug	29.53 "	750 mm	50 Ohms	LMR 240	Shielded	SMA Jack	Black	50 Ohms	6000 MHz	Panel Mount	Free Hanging (In-Line)	SMA to SMA	Female

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Assembly Coaxial SMA to SMA LMR 240 29.53" (750.00mm)
