S18DLGRYPT
ActiveBANNER ENGINEERING
S18 DAYLIGHT VISIBLE EZ LIGHT - 18 MM - IP67
Deep-Dive with AI
Search across all available documentation for this part.
S18DLGRYPT
ActiveBANNER ENGINEERING
S18 DAYLIGHT VISIBLE EZ LIGHT - 18 MM - IP67
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | S18DLGRYPT |
|---|---|
| Current | 25 mA |
| Ingress Protection | NEMA 4X, IP69K, IP67 |
| Lamp Color | Green, Yellow, Red |
| Lens Transparency | Clear |
| Millicandela Rating | 1.4 mcd, 2.3 mcd, 1.2 mcd |
| Panel Cutout Dimensions | 18 mm |
| Panel Cutout Dimensions | 0.71 " |
| Panel Cutout Shape | Round |
| Ratings | DC |
| Termination Style | Screw Terminal |
| Type | LED |
| Voltage [Max] | 30 V |
| Voltage [Min] | 10 V |
S18DL Series
| Part | Lens Transparency | Panel Cutout Dimensions | Panel Cutout Dimensions | Current | Ingress Protection | Millicandela Rating [custom] | Millicandela Rating [custom] | Termination Style | Lamp Color | Voltage [Max] | Voltage [Min] | Type | Ratings | Panel Cutout Shape | Millicandela Rating | Wavelength - Peak | Lens Size [diameter] | Wavelength - Peak [custom] | Wavelength - Peak [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
BANNER ENGINEERING | Diffused | 0.709 in | 18 mm | 25 mA | IP67 IP69K NEMA 4X | 2.3 mcd | 1.4 mcd | Quick Connect | Green Red | 30 V | 10 V | LED | DC | Round | |||||
BANNER ENGINEERING | Diffused | 0.709 in | 18 mm | 25 mA | IP67 IP69K NEMA 4X | Quick Connect | Green Red Yellow | 30 V | 10 V | LED | DC | Round | 1.2 mcd 1.4 mcd 2.3 mcd | ||||||
BANNER ENGINEERING | 25 mA | IP67 IP69K | Orange | 30 V | 10 V | LED | DC | 608 nm | 16 mm | ||||||||||
BANNER ENGINEERING | Clear | 0.71 " | 18 mm | 25 mA | IP67 IP69K NEMA 4X | Screw Terminal | Green Red Yellow | 30 V | 10 V | LED | DC | Round | 1.2 mcd 1.4 mcd 2.3 mcd | ||||||
BANNER ENGINEERING | 25 mA | IP67 IP69K | Screw Terminal | Blue Red White | 30 V | 10 V | LED | DC | 16 mm | 625 nm | 470 nm | ||||||||
BANNER ENGINEERING | Diffused | 0.709 in | 18 mm | 25 mA | IP67 IP69K NEMA 4X | Wire Leads | Green Red Yellow | 30 V | 10 V | LED | DC | Round | 1.2 mcd 1.4 mcd 2.3 mcd | ||||||
BANNER ENGINEERING | 25 mA | IP67 IP69K | White | 30 V | 10 V | LED | DC | 16 mm | |||||||||||
BANNER ENGINEERING | Diffused | 0.709 in | 18 mm | 60 mA | IP67 IP69K NEMA 4X | Quick Connect | 30 V | 9 V | LED | DC | Round | 20 mcd | |||||||
BANNER ENGINEERING | 25 mA | IP67 IP69K | Screw Terminal | Orange | 30 V | 10 V | LED | DC | 608 nm | 16 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
S18DL Series
LED Panel Indicator Green, Red, Yellow Clear 10V ~ 30V 25mA Screw Terminal
