XVR13M04L

Active

SQUARE D BY SCHNEIDER ELECTRIC

BEACON, RED, ROTATING, 5W, IP66, IP67, 130MM DIA., 179MM EXT. DEPTH

Search across all available documentation for this part.

Active

SQUARE D BY SCHNEIDER ELECTRIC

BEACON, RED, ROTATING, 5W, IP66, IP67, 130MM DIA., 179MM EXT. DEPTH

Technical Specifications

Parameters and characteristics for this part

Part	Number of Stacks	Voltage - Supply	Type	Ingress Protection	Termination Style	Light Color	Operating Temperature [Max]	Operating Temperature [Min]	Function - Lighting	Weight	Weight	Weight
SQUARE D BY SCHNEIDER ELECTRIC XVR13M04L	1	230 VAC	Complete Unit	IP66/IP67	Screw Terminal	Red	50 °C	-30 ░C	Flashing Rotating	2.2 lbs	997.9 g
SQUARE D BY SCHNEIDER ELECTRIC XVR13G04L	1	120 VAC	Complete Unit	IP66/IP67	Wire Leads	Red	50 °C	-30 ░C	Rotating	2.2 lbs	997.9 g
SQUARE D BY SCHNEIDER ELECTRIC XVR13M05L	1	230 VAC	Complete Unit	IP66/IP67	Screw Terminal	Orange	50 °C	-30 ░C	Flashing Rotating	2.2 lbs	997.9 g
SQUARE D BY SCHNEIDER ELECTRIC XVR13G05L	1	120 VAC	Complete Unit	IP66/IP67	Wire Leads	Orange	50 °C	-30 ░C	Rotating	2.2 lbs	997.9 g
SQUARE D BY SCHNEIDER ELECTRIC XVR13B05L	1	24 VAC	Complete Unit	IP66/IP67	Screw Terminal	Orange	50 °C	-30 ░C	Flashing Rotating		1.8 lbs	816.5 g
SQUARE D BY SCHNEIDER ELECTRIC XVR13J05	1	12 VDC	Complete Unit	IP66	Screw Terminal	Orange	50 °C	-30 ░C	Flashing Rotating		1.8 lbs	816.5 g
SQUARE D BY SCHNEIDER ELECTRIC XVR13B04	1	24 VDC	Complete Unit	IP66	Screw Terminal	Red	50 °C	-30 ░C	Flashing Rotating		1.8 lbs	816.5 g
SQUARE D BY SCHNEIDER ELECTRIC XVR13B05	1	24 VDC	Complete Unit	IP66	Screw Terminal	Orange	50 °C	-30 ░C	Flashing Rotating		1.8 lbs	816.5 g

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Stack Light Complete Unit Red LED Screw Terminal
