FNP600-12G

Active

EOS Power India Private Ltd

AC/DC CONVERTER 12V 600W

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

AC/DC CONVERTER 12V 600W

Technical Specifications

Parameters and characteristics for this part

Specification	FNP600-12G

Applications	ITE (Commercial)
Current - Output 1	51 A
Efficiency	87 %
Features	Standby Output, PFC, Universal Input, Load Sharing, Adjustable Output, Remote Sense, I2C Interface
Minimum Load Required	False
Mounting Type	Rack Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Power (Watts)	600 W
Size / Dimension [x]	298.2 mm
Size / Dimension [x]	11.74 "
Size / Dimension [y]	1.6 "
Size / Dimension [y]	40.6 mm
Size / Dimension [z]	3.3 "
Size / Dimension [z]	83.8 mm
Type	Front End
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Isolation	4000 V
Voltage - Output 1	12 V

Part	Features	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Voltage - Isolation	Mounting Type	Applications	Power (Watts)	Minimum Load Required	Type	Efficiency	Number of Outputs	Voltage - Input [Min]	Voltage - Input [Max]	Current - Output 1
EOS Power India Private Ltd FNP600-48G	Adjustable Output I2C Interface Load Sharing PFC Remote Sense Standby Output Universal Input	3.3 "	1.6 "	40.6 mm	83.8 mm	298.2 mm	11.74 "	70 °C	0 °C	48 V	4000 V	Rack Mount	ITE (Commercial)	600 W		Front End	89 %	1	90 VAC	264 VAC
EOS Power India Private Ltd FNP600-12G	Adjustable Output I2C Interface Load Sharing PFC Remote Sense Standby Output Universal Input	3.3 "	1.6 "	40.6 mm	83.8 mm	298.2 mm	11.74 "	70 °C	0 °C	12 V	4000 V	Rack Mount	ITE (Commercial)	600 W		Front End	87 %	1	90 VAC	264 VAC	51 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	40	$ 781.25

General part information

Front End AC DC Converters 1 Output 12V 90 ~ 264 VAC Input

Technical documentation and resources

No documents available
