MR4A08BUYS45

Active

Everspin Technologies Inc.

IC RAM 16MBIT PARALLEL 44TSOP2

Search across all available documentation for this part.

Active

Everspin Technologies Inc.

IC RAM 16MBIT PARALLEL 44TSOP2

Technical Specifications

Parameters and characteristics for this part

Specification	MR4A08BUYS45

Access Time	45 ns
Memory Format	RAM
Memory Interface	Parallel
Memory Organization	2 M
Memory Size	16 Mb
Memory Type	Non-Volatile
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Package / Case	10.16 mm
Package / Case	10.16 mm
Package / Case	44-TSOP
Supplier Device Package	44-TSOP2
Technology	MRAM (Magnetoresistive RAM)
Voltage - Supply [Max]	3.6 V
Voltage - Supply [Min]	3 V
Write Cycle Time - Word, Page [custom]	45 ns
Write Cycle Time - Word, Page [custom]	45 ns

Part	Memory Size	Access Time	Mounting Type	Technology	Write Cycle Time - Word, Page	Voltage - Supply [Max]	Voltage - Supply [Min]	Memory Format	Memory Organization	Memory Type	Supplier Device Package	Memory Interface	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Write Cycle Time - Word, Page [custom]	Write Cycle Time - Word, Page [custom]
Everspin Technologies Inc. MR4A08BCMA35R	16 Mb	35 ns	Surface Mount	MRAM (Magnetoresistive RAM)	35 ns	3.6 V	3 V	RAM	2 M	Non-Volatile	48-FBGA (10x10)	Parallel	48-LFBGA	85 °C	-40 °C
Everspin Technologies Inc. MR4A08BYS35R	16 Mb	35 ns	Surface Mount	MRAM (Magnetoresistive RAM)	35 ns	3.6 V	3 V	RAM	2 M	Non-Volatile	44-TSOP2	Parallel	44-TSOP	70 °C	0 °C	10.16 mm	10.16 mm
Everspin Technologies Inc. MR4A08BUYS45R	16 Mb	45 ns	Surface Mount	MRAM (Magnetoresistive RAM)		3.6 V	3 V	RAM	2 M	Non-Volatile	44-TSOP2	Parallel	44-TSOP	125 °C	-40 °C	10.16 mm	10.16 mm	45 ns	45 ns
Everspin Technologies Inc. MR4A08BUYS45	16 Mb	45 ns	Surface Mount	MRAM (Magnetoresistive RAM)		3.6 V	3 V	RAM	2 M	Non-Volatile	44-TSOP2	Parallel	44-TSOP	125 °C	-40 °C	10.16 mm	10.16 mm	45 ns	45 ns
Everspin Technologies Inc. MR4A08BCYS35	16 Mb	35 ns	Surface Mount	MRAM (Magnetoresistive RAM)	35 ns	3.6 V	3 V	RAM	2 M	Non-Volatile	44-TSOP2	Parallel	44-TSOP	85 °C	-40 °C	10.16 mm	10.16 mm
Everspin Technologies Inc. MR4A08BYS35	16 Mb	35 ns	Surface Mount	MRAM (Magnetoresistive RAM)	35 ns	3.6 V	3 V	RAM	2 M	Non-Volatile	44-TSOP2	Parallel	44-TSOP	70 °C	0 °C	10.16 mm	10.16 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

MRAM (Magnetoresistive RAM) Memory IC 16Mbit Parallel 45 ns 44-TSOP2
