S101DH2
ObsoleteSharp Microelectronics
DIP-16 SOLID STATE RELAYS (TRIAC OUTPUT)
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
S101DH2
ObsoleteSharp Microelectronics
DIP-16 SOLID STATE RELAYS (TRIAC OUTPUT)
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | S101DH2 |
|---|---|
| Approval Agency | CSA, TUV, UL |
| Load Current | 1.5 A |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -25 °C |
| Output Type | AC, Zero Cross |
| Package / Case | 0.3 in, 10 Leads |
| Package / Case | 16-DIP |
| Package / Case | 7.62 mm |
| Supplier Device Package | 16-DIP |
| Termination Style | PC Pin |
| Voltage - Input | 1.2 VDC |
| Voltage - Load [Max] | 120 V |
| Voltage - Load [Min] | 0 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| LCSC | Piece | 1 | $ 3.34 | |
| 200 | $ 1.33 | |||
| 500 | $ 1.29 | |||
| 1000 | $ 1.27 | |||
Description
General part information
S101DH Series
Solid State SPST-NO (1 Form A) 16-DIP (0.300", 7.62mm), 10 Leads
