FI2D144RK

Active

Belden Inc.

CBL FIBER OPTIC 125UM MULTIMODE

Search across all available documentation for this part.

Active

Belden Inc.

CBL FIBER OPTIC 125UM MULTIMODE

Technical Specifications

Parameters and characteristics for this part

Specification	FI2D144RK

Cladding Diameter [diameter]	125 µm
Core Diameter [diameter]	50 µm
Features	Rip Cord
Features	144 Fibers
Jacket (Insulation) Diameter [diameter]	1.076 in
Jacket (Insulation) Diameter [diameter]	27.33 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Orange
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Ratings	OFNR
Style	Multiple Fibers
Tensile Strength	40.8 kg
Type	Multimode

Part	Tensile Strength	Ratings	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Operating Temperature [Min]	Operating Temperature [Max]	Core Diameter [diameter]	Style	Jacket (Insulation) Material	Type	Cladding Diameter [diameter]	Features	Features
Belden Inc. FI2D144RK	40.8 kg	OFNR	1.076 in	27.33 mm	Orange	-20 C	70 °C	50 µm	Multiple Fibers	Poly-Vinyl Chloride (PVC)	Multimode	125 µm	Rip Cord	144 Fibers

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Fiber Optic Cable Orange Multimode 125µm

Technical documentation and resources
