CBM-6015V-144

Obsolete

CUI Devices

FAN BLOWER 60X15MM 12VDC WIRE

Search across all available documentation for this part.

Obsolete

CUI Devices

FAN BLOWER 60X15MM 12VDC WIRE

Technical Specifications

Parameters and characteristics for this part

Specification	CBM-6015V-144

Air Flow	5.1 CFM
Air Flow	0.143 m³/min
Approval Agency	cURus, CE, TUV
Current Rating (Amps)	78 mA
Fan Type	Blower
Features	Auto Restart
Lifetime @ Temp.	70000 Hrs
Material - Blade	Polybutylene Terephthalate (PBT)
Noise	36 dB
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
RPM	4400 RPM
Size / Dimension	Square/Rounded
Size / Dimension [x]	60 mm
Size / Dimension [z]	60 mm
Static Pressure	0.33 in H2O
Static Pressure	82.2 Pa
Termination	2 Wire Leads
Voltage - Rated	12 VDC
Voltage Range [Max]	13.8 VDC
Voltage Range [Min]	4.5 V
Weight	0.079 lb
Weight	35.83 g
Width [x]	15 mm

Part	Power (Watts)	Noise	Static Pressure	Static Pressure	Termination	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Approval Agency	Air Flow	Air Flow	Voltage Range [Min]	Voltage Range [Max]	Material - Blade	RPM	Lifetime @ Temp.	Voltage - Rated	Width [x]	Current Rating (Amps)	Weight	Weight	Size / Dimension	Size / Dimension [z]	Size / Dimension [x]	Features	Fan Type	Air Flow
CUI Devices CBM-6015V-150	1.25 W	40.2 dB(A)	0.44 in H2O	109.6 Pa	2 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	0.16 m³/min	5.7 CFM	4.5 V	13.8 VDC	Polybutylene Terephthalate (PBT)	5000 RPM	70000 Hrs	12 VDC	15 mm	0.104 A	0.079 lb	35.83 g	Square/Rounded	60 mm	60 mm	Auto Restart	Blower
CUI Devices CBM-6015V-144		36 dB	0.33 in H2O	82.2 Pa	2 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	5.1 CFM		4.5 V	13.8 VDC	Polybutylene Terephthalate (PBT)	4400 RPM	70000 Hrs	12 VDC	15 mm	78 mA	0.079 lb	35.83 g	Square/Rounded	60 mm	60 mm	Auto Restart	Blower	0.143 m³/min
CUI Devices CBM-6015V-144		36 dB	0.33 in H2O	82.2 Pa	2 Wire Leads	70 °C	70 °C	-10 °C	-10 °C	CE cURus TUV	5.1 CFM		4.5 V	13.8 VDC	Polybutylene Terephthalate (PBT)	4400 RPM	70000 Hrs	12 VDC	15 mm	78 mA	0.079 lb	35.83 g	Square/Rounded	60 mm	60 mm	Auto Restart	Blower	0.143 m³/min

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fan Blower 12VDC Square/Rounded - 60mm L x 60mm H omniCOOL™ Magnetic Sleeve 5.1 CFM (0.143m³/min) 2 Wire Leads
