WLA26P-34162100A00

Active

SICK, Inc.

PHOTOELECTRIC SENSOR, 18M, NPN-PNP, 30V ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

SICK, Inc.

PHOTOELECTRIC SENSOR, 18M, NPN-PNP, 30V ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Part	Output Configuration	Connection Method	Voltage - Supply [Max]	Voltage - Supply [Min]	Sensing Method	Response Time	Light Source	Light Source	Cable Length	Cable Length	Sensing Distance [Max]	Sensing Distance [Max]	Sensing Distance [Min]	Sensing Distance [Min]	Ingress Protection	Adjustment Type	Operating Temperature [Min]	Operating Temperature [Max]
SICK, Inc. WLA26P-34162100A00	NPN/PNP Push-Pull	Cable with Connector	30 VDC	10 VDC	Retroreflective	500 µs	635 nm	Red	270 mm	10.63 in	59.1 ft	18 m	0 mm	0 "	IP66 IP67	Adjustable	-40 °C	60 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 287.50
Newark	Each	1	$ 362.39
		5	$ 337.02

General part information

Retroreflective Optical Sensor 0' ~ 59.10' (0 ~ 18m) Push-Pull, NPN/PNP
