SML-P11UTT86R
ActiveCHIP LED, TYPE=PICOLED?-ECO/MINI-MOLD, PACKAGE=1.0X0.6(T=0.2), COLOR = YELLOW, ( ?D=586, IV=7.6MCD, IF=1MA, VF=1.9V, IF=1MA ) RO
Deep-Dive with AI
Search across all available documentation for this part.
SML-P11UTT86R
ActiveCHIP LED, TYPE=PICOLED?-ECO/MINI-MOLD, PACKAGE=1.0X0.6(T=0.2), COLOR = YELLOW, ( ?D=586, IV=7.6MCD, IF=1MA, VF=1.9V, IF=1MA ) RO
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SML-P11UTT86R |
|---|---|
| Color | Red |
| Configuration | Standard |
| Current - Test | 1 mA |
| Height (Max) [Max] | 0.25 mm |
| Lens Color | Colorless |
| Lens Size | 0.6 mm |
| Lens Style | Square with Flat Top |
| Lens Transparency | Clear |
| Millicandela Rating | 2.5 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1006 Metric) |
| Size / Dimension [x] | 1 mm |
| Size / Dimension [y] | 0.6 mm |
| Supplier Device Package | 1006 |
| Supplier Device Package | 0402 |
| Voltage - Forward (Vf) (Typ) | 1.8 V |
| Wavelength - Dominant | 621 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.31 | |
| 10 | $ 0.21 | |||
| 100 | $ 0.15 | |||
| 500 | $ 0.12 | |||
| 1000 | $ 0.11 | |||
| 2000 | $ 0.10 | |||
| Digi-Reel® | 1 | $ 0.31 | ||
| 10 | $ 0.21 | |||
| 100 | $ 0.15 | |||
| 500 | $ 0.12 | |||
| 1000 | $ 0.11 | |||
| 2000 | $ 0.10 | |||
| Tape & Reel (TR) | 5000 | $ 0.10 | ||
| 10000 | $ 0.09 | |||
| 15000 | $ 0.09 | |||
| 25000 | $ 0.08 | |||
| 35000 | $ 0.08 | |||
| 50000 | $ 0.08 | |||
| 125000 | $ 0.08 | |||
| Newark | Each (Supplied on Full Reel) | 1 | $ 0.06 | |
Description
General part information
SML-P11VT(R) Series
ROHM's PICOLED™-Using its second-to-none merits from ultra-small & ultra-thin configuration, ultra-fine LED matrices beyond common sense can be made, boosting the level of expression ultimately. Also, this device is indispensable for future design-in for whatever application requiring downsizing.
Documents
Technical documentation and resources
