PSK3620-7

Active

EOS Power India Private Ltd

DC/DC CONVERTER 36V 720W

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

DC/DC CONVERTER 36V 720W

Technical Specifications

Parameters and characteristics for this part

Part	Standard Number	Voltage - Output 1	DC Voltage - Input (Max) [Max]	Approval Agency	Applications	Current - Output (Max) [Max]	Input Type	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	DC Voltage - Input (Min) [Min]	Features	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Efficiency	Mounting Type	Type	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]
EOS Power India Private Ltd PSK3620-7EB	60950-1	36 V	80 V	cCSAus CE	ITE (Commercial) Railway	20 A	DC	1	-25 °C	71 °C	720 W	42 V	Adjustable Output Remote On/Off Remote Sense	4.37 "	171.9 mm	6.77 in	3.15 "	80 mm	111 mm	95 %
EOS Power India Private Ltd PSK3620-7		36 V		cCSAus CE	ITE (Commercial) Railway	20 A		1	-25 °C	71 °C	720 W			4.37 "	171 mm	6.73 in	3.15 "	80 mm	111 mm	95 %	Chassis Mount	Conformal Coated Enclosed	80 V	42 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed, Conformal Coated DC DC Converter 1 Output 36V 20A 80V Input
