C1356.21.90
ActivePrysmian Group
CABLE SPKR 2COND 24AWG CLEAR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
C1356.21.90
ActivePrysmian Group
CABLE SPKR 2COND 24AWG CLEAR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | C1356.21.90 |
|---|---|
| Cable Type | Speaker |
| Conductor Material | Copper, Tinned, Copper, Bare |
| Conductor Strand [custom] | 32 AWG |
| Conductor Strand [custom] | 7 |
| Jacket (Insulation) Diameter [diameter] | 0.117 in |
| Jacket (Insulation) Diameter [diameter] | 2.97 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.406 mm |
| Jacket (Insulation) Thickness | 0.016 in |
| Jacket Color | Clear |
| Length | 1000 ft |
| Length | 304.8 m, 15.24 m |
| Length [x] | 50 ft, 100 ft |
| Length [x] | 30.5 m |
| Number of Conductors | 2 |
| Usage | Home, Audio-Video |
| Voltage | 120 V |
| Wire Gauge | 24 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 10.74 | |
| 1 | $ 90.20 | |||
| 3 | $ 83.45 | |||
| 5 | $ 8.78 | |||
| 5 | $ 80.56 | |||
| 7 | $ 78.63 | |||
| 10 | $ 76.70 | |||
| 10 | $ 6.83 | |||
| 25 | $ 71.87 | |||
| 50 | $ 68.02 | |||
| 100 | $ 65.12 | |||
| Spool | 1 | $ 19.60 | ||
| 5 | $ 16.03 | |||
| 10 | $ 12.47 | |||
Description
General part information
C1356 Series
2 Conductor Speaker Cable Clear 24 AWG 1000.0' (304.8m)
Documents
Technical documentation and resources
