KMD15-1515

TDK-LAMBDA

AC/DC PCB MOUNT POWER SUPPLY (PSU), MEDICAL, 2 OUTPUT, 15 W, 15 V, 500 MA, -15 V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Technical Data Sheet EN

KMD15-1515

TDK-LAMBDA

AC/DC PCB MOUNT POWER SUPPLY (PSU), MEDICAL, 2 OUTPUT, 15 W, 15 V, 500 MA, -15 V

Deep-Dive with AI

DocumentsDatasheet Technical Data Sheet EN

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	KMD15-1515

Applications	Medical
Approval Agency	IEC, CE, EN, UL
Current - Output (Max)	500 mA
Current - Output (Max)	500 mA
Efficiency	81 %
Features	Universal Input
Line Regulation	0.5 %
Load Regulation	1 %
Mounting Type	Through Hole
Number of Outputs	2
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Package / Case	9-DIP Module, 5 Leads
Power (Watts)	15 W
Size / Dimension [x]	2.52 in
Size / Dimension [x]	64 mm
Size / Dimension [y]	45.6 mm
Size / Dimension [y]	1.8 in
Size / Dimension [z]	0.93 in
Size / Dimension [z]	23.5 mm
Standard Number	60950-1, 60601-1, 62368-1
Type	Enclosed
Voltage - Input [Max]	375 VDC, 264 VAC
Voltage - Input [Min]	90 VAC, 100 V
Voltage - Output 1	15 V
Weight	0.265 lb
Weight	120.2 g

KMD15 Series

Part	Line Regulation	Standard Number	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 1	Type	Features	Voltage - Input [Min]	Voltage - Input [Max]	Weight	Weight	Power (Watts)	Load Regulation	Approval Agency	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Package / Case	Current - Output (Max)	Current - Output (Max)	Mounting Type	Number of Outputs	Applications	Efficiency
TDK-LAMBDA KMD15-1515	0.5 %	60601-1 60950-1 62368-1	-25 °C	70 °C	15 V	Enclosed	Universal Input	90 VAC 100 V	264 VAC 375 VDC	0.265 lb	120.2 g	15 W	1 %	CE EN IEC UL	45.6 mm	2.52 in	1.8 in	64 mm	0.93 in	23.5 mm	9-DIP Module 5 Leads	500 mA	500 mA	Through Hole	2	Medical	81 %

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 63.26
		10	$ 48.95
Newark	Each	1	$ 63.26
		10	$ 46.99

Description

General part information

KMD15 Series

The KMD15-1515 is a 2-output 15W AC/DC PCB mount Power Supply with fixed output. It offers small size and lightweight, wide range input and minimizes PCB space. It is global use with no manual intervention.
