JD54LS27BDA

Active

National Semiconductor

IC GATE NOR TRPL 3-INP

Search across all available documentation for this part.

Active

National Semiconductor

IC GATE NOR TRPL 3-INP

Technical Specifications

Parameters and characteristics for this part

Specification	JD54LS27BDA

null

Part	Supplier Device Package	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Package / Case	Mounting Type	Number of Inputs	Number of Circuits	Input Logic Level - Low	Current - Quiescent (Max) [Max]	Max Propagation Delay @ V, Max CL	Operating Temperature [Min]	Operating Temperature [Max]	Logic Type	Voltage - Supply [Min]	Voltage - Supply [Max]
National Semiconductor JD54LS27BDA
National Semiconductor DM54LS27J/883	14-CDIP	4 mA	400 µA	14-CDIP	Through Hole	3	3	0.7 V	6.8 mA	18 ns	-55 °C	125 °C	NOR Gate	4.5 V	5.5 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	19	$ 16.47

General part information

IC Channel

Technical documentation and resources

No documents available
