2241-C1X06G00DBU

Active

Oupiin

PIN HEADER, TYPE C, SINGLE ROW,

Search across all available documentation for this part.

Active

Oupiin

PIN HEADER, TYPE C, SINGLE ROW,

Technical Specifications

Parameters and characteristics for this part

Specification	2241-C1X06G00DBU

Connector Type	Header
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	Flash
Contact Finish Thickness - Post	Flash
Contact Shape	Square
Contact Type	Male Pin
Fastening Type	Push-Pull
Mounting Type	Surface Mount
Number of Positions	6
Number of Positions Loaded	All
Number of Rows	1
Termination	Solder

Part	Contact Finish - Post	Number of Positions Loaded	Contact Shape	Contact Finish Thickness - Post	Number of Rows	Connector Type	Termination	Number of Positions	Contact Type	Fastening Type	Contact Finish - Mating	Mounting Type	Contact Finish Thickness - Mating
Oupiin 2241-C1X06G00DBU	Gold	All	Square	Flash	1	Header	Solder	6	Male Pin	Push-Pull	Gold	Surface Mount	Flash

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Connector Header Surface Mount 6 position

Technical documentation and resources

No documents available
