Q302013PCI

Active

Hoffman Enclosures, Inc.

BOX PLASTIC GRY 11.81"L X 7.87"W

Search across all available documentation for this part.

Active

Hoffman Enclosures, Inc.

BOX PLASTIC GRY 11.81"L X 7.87"W

Technical Specifications

Parameters and characteristics for this part

Specification	Q302013PCI

Area (L x W)	93 in˛
Area (L x W)	600 cm²
Color	Gray
Container Type	Box
Design	Cover Included
Features	Wall Mount, PCB Supports, Sealing Gasket
Height [z]	5.157 in
Height [z]	131 mm
Material	Plastic, Polycarbonate
Ratings	NEMA 12, IP66, NEMA 4, UL-508A, NEMA 13, NEMA 4X
Size / Dimension [x]	300 mm
Size / Dimension [x]	11.811 in
Size / Dimension [y]	200 mm
Size / Dimension [y]	7.874 "
Thickness	0.157 in
Thickness	4 mm
Weight	1.4 kg
Weight	3.1 lbs

Part	Ratings	Design	Material	Thickness	Thickness	Color	Weight	Weight	Height [z]	Height [z]	Container Type	Features	Area (L x W)	Area (L x W)	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]
Hoffman Enclosures, Inc. Q302013PCI	IP66 NEMA 12 NEMA 13 NEMA 4 NEMA 4X UL-508A	Cover Included	Plastic Polycarbonate	0.157 in	4 mm	Gray	1.4 kg	3.1 lbs	5.157 in	131 mm	Box	PCB Supports Sealing Gasket Wall Mount	93 in˛	600 cm²	200 mm	7.874 "	300 mm	11.811 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Box Plastic, Polycarbonate Gray Cover Included 11.811" L x 7.874" W (300.00mm x 200.00mm) X 5.157" (131.00mm)
