AFB0912LB
ObsoleteDelta Electronics
FAN AXIAL 92X15MM 12VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
AFB0912LB
ObsoleteDelta Electronics
FAN AXIAL 92X15MM 12VDC WIRE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AFB0912LB |
|---|---|
| Air Flow | 26.1 CFM |
| Air Flow | 0.731 m³/min |
| Approval Agency | UL, CE, VDE, CSA |
| Bearing Type | Ball |
| Current Rating (Amps) | 100 mA |
| Fan Type | Tubeaxial |
| Lifetime @ Temp. | 70000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Noise | 25 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -10 °C |
| Operating Temperature [Min] | -10 °C |
| Power (Watts) | 1.2 W |
| RPM | 1800 RPM |
| Static Pressure | 0.045 in H2O |
| Static Pressure | 11.2 Pa |
| Termination | 2 Wire Leads |
| Voltage - Rated | 12 VDC |
| Voltage Range [Max] | 13.8 VDC |
| Voltage Range [Min] | 5 VDC |
| Weight | 0.154 lb |
| Weight | 69.85 g |
| Width [x] | 15 mm |
AFB0912 Series
| Part | Voltage Range [Min] | Voltage Range [Max] | Static Pressure | Static Pressure | Termination | Noise | Air Flow | Air Flow | Width [x] | Operating Temperature [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Min] | Weight | Weight | Bearing Type | Voltage - Rated | Lifetime @ Temp. | Approval Agency | Material - Frame | RPM | Current Rating (Amps) | Fan Type | Power (Watts) | Material - Blade | Width [y] | Features | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Delta Electronics | 5 VDC | 13.8 VDC | 0.045 in H2O | 11.2 Pa | 2 Wire Leads | 25 dB(A) | 26.1 CFM | 0.731 m³/min | 15 mm | 70 °C | 70 °C | -10 °C | -10 °C | 0.154 lb | 69.85 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 1800 RPM | 100 mA | Tubeaxial | 1.2 W | Plastic | |||
Delta Electronics | 5 VDC | 12.6 VDC | 0.526 in H2O | 131 Pa | 3 Wire Leads | 53 dB | 102.6 CFM | 2.87 m³/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.267 lb | 121.11 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 4800 RPM | 750 mA | Tubeaxial | 9 W | Plastic | 25.4 mm | Locked Rotor Protection Speed Sensor (Tach) | ||
Delta Electronics | 7 V | 13.8 VDC | 0.1 in H2O | 24.9 Pa | 2 Wire Leads | 25 dB(A) | 37.1 CFM | 1.04 mł/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.219 lb | 99.34 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 2100 RPM | 70 mA | Tubeaxial | 840 mW | Plastic | 25.4 mm | |||
Delta Electronics | 5 VDC | 13.8 VDC | 0.191 in H2O | 47.6 Pa | 2 Wire Leads | 37 dB | 59.9 CFM | 1.68 mł/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.267 lb | 121.11 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 2800 RPM | 0.21 A | Tubeaxial | 2.52 W | Plastic | 25.4 mm | IP55 - Dust Protected Water Resistant | ||
Delta Electronics | 5 VDC | 13.8 VDC | 0.079 in H2O | 19.7 Pa | 2 Wire Leads | 32.5 dB | 36.5 CFM | 1.02 m³/min | 15 mm | 70 °C | 70 °C | -10 °C | -10 °C | 0.154 lb | 69.85 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 2300 RPM | Tubeaxial | 1.56 W | Plastic | ||||
Delta Electronics | 7 V | 13.8 VDC | 0.084 in H2O | 20.9 Pa | 3 Wire Leads | 28.5 dB(A) | 41 CFM | 1.15 mł/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.203 lb | 92.08 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 2100 RPM | Tubeaxial | Plastic | 20 mm | Locked Rotor Protection Speed Sensor (Tach) | ||||
Delta Electronics | 7 V | 13.8 VDC | 0.084 in H2O | 20.9 Pa | 2 Wire Leads | 28.5 dB(A) | 41 CFM | 1.15 mł/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.203 lb | 92.08 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 2100 RPM | Tubeaxial | Plastic | 20 mm | |||||
Delta Electronics | 7 V | 13.8 VDC | 0.302 in H2O | 75.2 Pa | 3 Wire Leads | 45 dB(A) | 67.8 CFM | 1.9 m³/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.218 lb | 98.88 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 3800 RPM | 400 mA | Tubeaxial | 4.8 W | Plastic | 25.4 mm | Locked Rotor Protection Speed Sensor (Tach) | ||
Delta Electronics | 7 V | 13.8 VDC | 0.13 in H2O | 32.4 Pa | 2 Wire Leads | 30 dB(A) | 43.8 CFM | 1.23 m³/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.218 lb | 98.88 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 2450 RPM | 110 mA | Tubeaxial | 1.32 W | Plastic | 25.4 mm | |||
Delta Electronics | 5 VDC | 13.8 VDC | 0.133 in H2O | 33.1 Pa | 3 Wire Leads | 31.5 dB | 49.5 CFM | 1.39 m³/min | 70 °C | 70 °C | -10 °C | -10 °C | 0.267 lb | 121.11 g | Ball | 12 VDC | 70000 Hrs | CE CSA UL VDE | Plastic | 2300 RPM | 120 mA | Tubeaxial | 1.44 W | Plastic | 25.4 mm | Locked Rotor Protection Speed Sensor (Tach) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 15.16 | |
| 10 | $ 12.43 | |||
| 25 | $ 11.48 | |||
| 50 | $ 10.81 | |||
| 100 | $ 10.18 | |||
| 250 | $ 9.40 | |||
| 500 | $ 8.85 | |||
Description
General part information
AFB0912 Series
Fan Tubeaxial 12VDC Square - 92mm L x 92mm H Ball 26.1 CFM (0.731m³/min) 2 Wire Leads
