82103C

Active

Murata Power Solutions Inc.

INDUCTOR, UNSHIELDED, 10UH, 0.5A, 10% ROHS COMPLIANT: YES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsProduct Change Notice EN Datasheet

82103C

Active

Murata Power Solutions Inc.

INDUCTOR, UNSHIELDED, 10UH, 0.5A, 10% ROHS COMPLIANT: YES

Deep-Dive with AI

DocumentsProduct Change Notice EN Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	82103C

Current Rating (Amps)	0.5 A
DC Resistance (DCR) [Max]	400 mOhm
Frequency - Self Resonant	38 MHz
Height - Seated (Max) [Max] [z]	0.091 "
Height - Seated (Max) [Max] [z]	2.3 mm
Inductance	10 µH
Inductance Frequency - Test	10 kHz
Mounting Type	Surface Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	1210
Package / Case	3225 Metric
Q @ Freq	1 MHz, 35
Shielding	Unshielded
Size / Dimension [x]	3.2 mm
Size / Dimension [x]	0.126 in
Size / Dimension [y]	2.5 mm
Size / Dimension [y]	0.098 in
Supplier Device Package	1210
Tolerance	10 %
Type	Wirewound

82 Series

Part	Frequency - Self Resonant	DC Resistance (DCR) [Max]	Inductance Frequency - Test	Package / Case	Package / Case	Q @ Freq	Inductance	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Tolerance	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Current Rating (Amps)	Type	Shielding	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Supplier Device Package	DC Resistance (DCR)
Murata Power Solutions Inc. 82154C	11 MHz	5.9 Ohm	10 kHz	1210	3225 Metric	40 800 kHz	150 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	10 %	85 °C	-40 °C	Surface Mount	130 mA	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82334C	9 MHz	13.5 Ohm	10 kHz	1210	3225 Metric	40 800 kHz	330 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	10 %	85 °C	-40 °C	Surface Mount	80 mA	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82152C	103 MHz	68 mOhm	10 kHz	1210	3225 Metric	1 MHz 18	1.5 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	20 %	85 °C	-40 °C	Surface Mount	1.4 A	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82682C			10 kHz	1210	3225 Metric	1 MHz 20	6.8 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	20 %	85 °C	-40 °C	Surface Mount	0.64 A	Wirewound	Unshielded	0.091 "	2.3 mm	1210	270 mOhm
Murata Power Solutions Inc. 82103C	38 MHz	400 mOhm	10 kHz	1210	3225 Metric	1 MHz 35	10 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	10 %	85 °C	-40 °C	Surface Mount	0.5 A	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82223C	25 MHz	920 mOhm	10 kHz	1210	3225 Metric	1 MHz 35	22 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	10 %	85 °C	-40 °C	Surface Mount	320 mA	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82683C	15 MHz	2.55 Ohm	10 kHz	1210	3225 Metric	1 MHz 40	68 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	10 %	85 °C	-40 °C	Surface Mount	0.2 A	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82472C	58 MHz	190 mOhm	10 kHz	1210	3225 Metric	1 MHz 20	4.7 ÁH	3.2 mm	2.5 mm	0.126 in	0.098 in	20 %	85 °C	-40 °C	Surface Mount	800 mA	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82222C	85 MHz	104 mOhm	10 kHz	1210	3225 Metric	1 MHz 18	2.2 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	20 %	85 °C	-40 °C	Surface Mount	1.1 A	Wirewound	Unshielded	0.091 "	2.3 mm	1210
Murata Power Solutions Inc. 82153C	31 MHz	560 mOhm	10 kHz	1210	3225 Metric	1 MHz 35	15 µH	3.2 mm	2.5 mm	0.126 in	0.098 in	10 %	85 °C	-40 °C	Surface Mount	400 mA	Wirewound	Unshielded	0.091 "	2.3 mm	1210

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.67
		10	$ 0.58
		25	$ 0.53
		50	$ 0.48
		100	$ 0.43
		250	$ 0.40
		500	$ 0.35
		1000	$ 0.31
	Digi-Reel®	1	$ 0.67
		10	$ 0.58
		25	$ 0.53
		50	$ 0.48
		100	$ 0.43
		250	$ 0.40
		500	$ 0.35
		1000	$ 0.31
	Tape & Reel (TR)	2500	$ 0.30
		5000	$ 0.29
		12500	$ 0.28
		25000	$ 0.27
Newark	Each (Supplied on Cut Tape)	1	$ 0.78

Description

General part information

82 Series

10 µH Unshielded Wirewound Inductor 500 mA 400mOhm Max 1210 (3225 Metric)

Documents

Technical documentation and resources

Product Change Notice EN

Datasheet
