Technical Specifications
Parameters and characteristics for this part
| Specification | V82ZA20P |
|---|---|
| Capacitance @ Frequency | 9000 pF |
| Energy | 25 J |
| Maximum AC Volts [Max] | 50 V |
| Maximum DC Volts [Max] | 68 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 85 C |
| Operating Temperature [Min] | -55 C |
| Package / Case | Disc 20mm |
| Varistor Voltage (Max) [Max] | 90.2 V |
| Varistor Voltage (Min) [Min] | 73.8 V |
| Varistor Voltage (Typ) | 82 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
V82ZA20P Series
The ZA Series of transient voltage surge suppressors are radial-lead varistors (MOVs) designed for use in the protection of low and medium-voltage circuits and systems. Typical applications include motor control, telecom, automotive systems, solenoid, and power supply circuits to protect circuit board components and maintain data integrity. These devices are available in five model sizes: 5, 7, 10, 14, and 20mm, and feature a wide V DC voltage range of 5.5V to 615V. See ZA Series Device Ratings and Specifications table for part number and brand information.
