A3A-USB2-1-B
ActiveSwitch Components
BATT CHG USB AUTO ADAPT 5V 2.4A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
A3A-USB2-1-B
ActiveSwitch Components
BATT CHG USB AUTO ADAPT 5V 2.4A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | A3A-USB2-1-B |
|---|---|
| Approval Agency | UL |
| Battery Chemistry | Mobile Devices |
| Mounting Type | Auto Socket |
| Number of Cells | 2 |
| Operating Temperature [Max] | 45 °C |
| Operating Temperature [Min] | -20 C |
| Size / Dimension [x] | 2.48 " |
| Size / Dimension [x] | 63 mm |
| Size / Dimension [y] | 1.85 " |
| Size / Dimension [y] | 47 mm |
| Size / Dimension [z] | 24.13 mm |
| Size / Dimension [z] | 24.1 mm |
| Termination Style | USB A Receptacle (2) |
| Type | USB Auto Adapter |
| Voltage - Input [Max] | 24 V |
| Voltage - Input [Min] | 12 V |
| Voltage - Nominal | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 42.03 | |
| 10 | $ 38.67 | |||
| 25 | $ 35.26 | |||
| 50 | $ 30.86 | |||
| 100 | $ 28.58 | |||
| 250 | $ 26.28 | |||
| 500 | $ 24.12 | |||
| 1000 | $ 22.21 | |||
Description
General part information
A3A-USB2 Series
USB Auto Adapter Battery Charger 5V 2.4A
