80306C

Obsolete

Murata Power Solutions Inc.

FIXED IND 220UH 3A 100 MOHM TH

Search across all available documentation for this part.

Obsolete

Murata Power Solutions Inc.

FIXED IND 220UH 3A 100 MOHM TH

Technical Specifications

Parameters and characteristics for this part

Specification	80306C

Current Rating (Amps)	3 A
DC Resistance (DCR)	100 mOhm
Height - Seated (Max) [Max]	14.8 mm
Height - Seated (Max) [Max]	0.583 in
Inductance	220 µH
Mounting Type	Through Hole
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Package / Case	Horizontal, Corner Terminals, Radial
Shielding	Unshielded
Size / Dimension [x]	1.114 in
Size / Dimension [x]	28.3 mm
Size / Dimension [y]	28.3 mm
Size / Dimension [y]	1.114 in
Tolerance	10 %
Type	Toroidal

Part	Operating Temperature [Max]	Mounting Type	Current Rating (Amps)	Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Tolerance	Shielding	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	DC Resistance (DCR)	Inductance	DC Resistance (DCR) [Max]
Murata Power Solutions Inc. 80305C	70 °C	Through Hole	2 A	Toroidal	11 mm	0.433 in	Corner Terminals Horizontal Radial	10 %	Unshielded	0.866 in	0.866 in	22 mm	22 mm
Murata Power Solutions Inc. 80306C	70 °C	Through Hole	3 A	Toroidal			Corner Terminals Horizontal Radial	10 %	Unshielded	1.114 in	1.114 in	28.3 mm	28.3 mm	14.8 mm	0.583 in	100 mOhm	220 µH
Murata Power Solutions Inc. 80304C	70 °C	Through Hole	3.5 A	Toroidal			Corner Terminals Horizontal Radial	10 %	Unshielded	1.114 in	1.114 in	28.3 mm	28.3 mm	14.8 mm	0.583 in		150 µH	90 mOhm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

220 µH Unshielded Toroidal Inductor 3 A 100mOhm Max Radial, Horizontal, Corner Terminals
