1/8C24-P20-C

Active

ULTRAVOLT / Advanced Energy

NON-ISOLATED DC/DC CONVERTERS C-SERIES DC TO HVDC CONVERTER, SINGLE OUTPUT (UNIPOLAR), +24V INPUT, +125V HVOUT, 20W, THRU-HOLE MOUNT, REGULATED, STANDARD INTERFACE, ALUMINUM CASE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Datasheet

1/8C24-P20-C

Active

ULTRAVOLT / Advanced Energy

NON-ISOLATED DC/DC CONVERTERS C-SERIES DC TO HVDC CONVERTER, SINGLE OUTPUT (UNIPOLAR), +24V INPUT, +125V HVOUT, 20W, THRU-HOLE MOUNT, REGULATED, STANDARD INTERFACE, ALUMINUM CASE

Deep-Dive with AI

DocumentsDatasheet Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	1/8C24-P20-C

Applications	ITE (Commercial)
Approval Agency	CE, cURus
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	65 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	20 W
Size / Dimension [x]	4.75 "
Size / Dimension [x]	120.7 mm
Size / Dimension [y]	50.8 mm
Size / Dimension [y]	2 in
Size / Dimension [z]	1 "
Size / Dimension [z]	25.4 mm
Standard Number	60950-1, 62368-1
Type	Enclosed
Voltage - Input (Max) [Max]	30 V
Voltage - Input (Min) [Min]	23 V
Voltage - Output 1	125 V

4C24-N30 Series

Non-Isolated DC/DC Converters HPC-Series DC to HVDC Converter, Single output (Unipolar), +24V Input, -60kV DC HVout, 60W, Chassis/Thru-hole Mount, Regulated, I10 Interface 0 to +10 Monitors/Controls, Arc quenching, Right-angle Male DA-15 type connector,

...

Part	Type	Voltage - Input (Min) [Min]	Applications	Power (Watts)	Current - Output (Max)	Current - Output (Max)	Number of Outputs	Package / Case	Approval Agency	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Voltage - Output 1	Voltage - Output 2	Voltage - Input (Max) [Max]	Control Features	Current - Output (Max) [Max]	Features	Standard Number	Size / Dimension [y]	Size / Dimension [z]
ULTRAVOLT / Advanced Energy 1/8C24-NP250-1	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W	1 A	1 A	2	Module	CE cURus	114.3 mm	4.5 in	203.2 mm	8 "	1.08 "	27.4 mm	65 °C	-40 °C	Through Hole	125 V	-125 V	30 V	Active Floating Enable
ULTRAVOLT / Advanced Energy 1/8C24-N250-DA-H	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W			1	Module	CE cURus	114.3 mm	4.5 in	203.2 mm	8 "	1.46 "	37.2 mm	65 °C	-40 °C	Through Hole	125 V		30 V	Active Low Enable	2 A	Heat Sink
ULTRAVOLT / Advanced Energy 1/8C24-P20-C	Enclosed	23 V	ITE (Commercial)	20 W			1		CE cURus		2 in	120.7 mm	4.75 "	1 "		65 °C	-40 °C	Chassis Mount	125 V		30 V				60950-1 62368-1	50.8 mm	25.4 mm
ULTRAVOLT / Advanced Energy 1/4C24-N250-I5-H	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W			1	Module	CE cURus	114.3 mm	4.5 in	203.2 mm	8 "	1.46 "	37.2 mm	65 °C	-40 °C	Through Hole	250 V		30 V	Active Low Enable	1 A	Heat Sink	60950-1 62368-1
ULTRAVOLT / Advanced Energy 1/8C24-N250-DAR-H	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W			1	Module	CE cURus	114.3 mm	4.5 in	203.2 mm	8 "	1.46 "	37.2 mm	65 °C	-40 °C	Through Hole	125 V		30 V	Active Low Enable	2 A	Heat Sink
ULTRAVOLT / Advanced Energy 1/4C24-N125-I10-DAR-H	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W			1	Module	CE cURus	101.6 mm	4 "	114.3 mm	4.5 in	1.46 "	37.2 mm	65 °C	-40 °C	Through Hole	250 V		30 V	Active Low Enable	500 mA	Heat Sink	60950-1 62368-1
ULTRAVOLT / Advanced Energy 1/4C24-N250-I10-H	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W			1	Module	CE cURus	114.3 mm	4.5 in	203.2 mm	8 "	1.46 "	37.2 mm	65 °C	-40 °C	Through Hole	250 V		30 V	Active Low Enable	1 A	Heat Sink	60950-1 62368-1
ULTRAVOLT / Advanced Energy 1C24-N30-M	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	30 W			1	11-DIP Module	CE cURus	38.1 mm	1.5 in	94 mm	3.7 in	0.86 in	21.9 mm	65 °C	-40 °C	Through Hole	-1000 V		30 V	Active High Enable	30 mA
ULTRAVOLT / Advanced Energy 1/4C24-P125-I5	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W			1	Module	CE cURus	101.6 mm	4 "	114.3 mm	4.5 in	1.06 in	27 mm	65 °C	-40 °C	Through Hole	250 V		30 V	Active High Enable	500 mA		60950-1 62368-1
ULTRAVOLT / Advanced Energy 1/8C24-N125-I5-H	High Voltage - Non-Isolated Module	23 V	ITE (Commercial)	60 W			1	Module	CE cURus	101.6 mm	4 "	114.3 mm	4.5 in	1.46 "	37.2 mm	65 °C	-40 °C	Through Hole	125 V		30 V	Active Low Enable	1 A	Heat Sink

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 674.64
Sager	N/A	1	$ 874.75
		3	$ 850.45
		5	$ 838.80
		10	$ 827.46
		25	$ 805.69

Description

General part information

4C24-N30 Series

Documents

Technical documentation and resources

Datasheet

Document
