52-271.025
ActiveEAO
SWITCH SELECT 2POS DPST 5A 250V
Deep-Dive with AI
Search across all available documentation for this part.
52-271.025
ActiveEAO
SWITCH SELECT 2POS DPST 5A 250V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 52-271.025 |
|---|---|
| Approval Agency | CB, CSA, UL, CE |
| Circuit | DPST-NO/NC |
| Current Rating (Amps) | 5 A |
| Illumination | Illuminated |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Mechanical Life | 1000000 Cycles |
| Number of Positions | 2 |
| Operating Temperature [Max] | 55 °C |
| Operating Temperature [Min] | -25 °C |
| Panel Cutout Dimensions [diameter] | 16.2 mm |
| Switch Function | On-Off, Off-On |
| Termination Style | Solder Lug |
| Type | Standard |
| Voltage Rating - AC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 51.83 | |
| 10 | $ 44.71 | |||
| 25 | $ 42.14 | |||
| 50 | $ 40.30 | |||
| 100 | $ 38.53 | |||
| 250 | $ 36.31 | |||
Description
General part information
52-271 Series
Selector Switch 2 Position DPST-NO/NC 5A (AC) 250 V Panel Mount
