TSC-100-AFC-060
ActiveATC-Diversified Electronics
RELAY TIME DELAY 60SEC 1A 120V
Deep-Dive with AI
Search across all available documentation for this part.
TSC-100-AFC-060
ActiveATC-Diversified Electronics
RELAY TIME DELAY 60SEC 1A 120V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | TSC-100-AFC-060 |
|---|---|
| Contact Rating @ Voltage | 1 A, 120 VAC |
| Delay Time [Max] | 60 Sec |
| Delay Time [Min] | 0.6 Sec |
| Function | On-Delay |
| Mounting Type | Chassis Mount |
| Relay Type | Solid State Relay |
| Termination Style | Quick Connect |
| Timing Adjustment Method | Fixed |
| Timing Initiate Method | Input Voltage |
| Voltage - Supply [Max] | 240 VDC, 240 VAC |
| Voltage - Supply [Min] | 12 V, 24 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 179.69 | |
Description
General part information
TSC-100 Series
On-Delay Time Delay Relay SPST-NO (1 Form A) 0.6 Sec ~ 60 Sec Delay 1A @ 120VAC Chassis Mount
Documents
Technical documentation and resources
No documents available
