PR2C10DC12K

Active

Hasco Relays

277V@AC 12V 10A TWO SETS OF CONVERSION: 2C (DPDT-CONVERSION) PLUGIN POWER RELAYS ROHS

Search across all available documentation for this part.

Active

Hasco Relays

277V@AC 12V 10A TWO SETS OF CONVERSION: 2C (DPDT-CONVERSION) PLUGIN POWER RELAYS ROHS

Technical Specifications

Parameters and characteristics for this part

Part	Operating Temperature [Max]	Operating Temperature [Min]	Coil Current	Operate Time	Seal Rating	Switching Voltage	Coil Voltage	Coil Type	Must Release Voltage	Contact Material	Coil Insulation	Release Time	Contact Rating (Current)	Must Operate Voltage	Termination Style	Contact Form	Mounting Type	Switching Voltage [Max]
Hasco Relays PR2C10DC12K-1.5	85 °C	-40 °C	44 mA	15 ms	Sealed - Fully	277 VAC	12 VDC	Non Latching	1.2 VDC	Silver Alloy	Class B	5 ms	10 A	9.6 VDC	PC Pin	DPDT (2 Form C)	Through Hole
Hasco Relays PR2C10DC12K	85 °C	-40 °C	44 mA	15 ms			12 VDC	Non Latching	1.2 VDC	Silver Alloy	Class B	5 ms	10 A	9.6 VDC	PC Pin	DPDT (2 Form C)	Through Hole	277 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Relay DPDT (2 Form C) 12VDC Coil Through Hole
