KVN1.50YL25

Active

Techflex

EXPAND SLEEVE 1.5" X 25' YELLOW

Search across all available documentation for this part.

Active

Techflex

EXPAND SLEEVE 1.5" X 25' YELLOW

Technical Specifications

Parameters and characteristics for this part

Specification	KVN1.50YL25

Color	Yellow
Diameter - Inside, Expanded [diameter]	2 in
Diameter - Inside, Expanded [diameter]	50.8 mm
Diameter - Inside, Non-Expanded [diameter]	1.5 in
Diameter - Inside, Non-Expanded [diameter]	38.1 mm
Environment Protection	Environment Resistant
Features	Clean Cut
Length [x]	25 ft
Length [x]	7.62 m
Material	Aramid, Halogen Free
Operating Temperature [Max]	160 °C
Operating Temperature [Min]	-170 °C
Type	Sleeve
Type Attributes	Expandable
Wall Thickness [custom]	0.51 mm
Wall Thickness [custom]	0.02 in

Part	Environment Protection	Diameter - Inside, Expanded [diameter]	Diameter - Inside, Expanded [diameter]	Type	Features	Length [x]	Length [x]	Diameter - Inside, Non-Expanded [diameter]	Diameter - Inside, Non-Expanded [diameter]	Wall Thickness [custom]	Wall Thickness [custom]	Type Attributes	Color	Operating Temperature [Max]	Operating Temperature [Min]	Material
Techflex KVN1.50YL25	Environment Resistant	2 in	50.8 mm	Sleeve	Clean Cut	25 ft	7.62 m	1.5 in	38.1 mm	0.51 mm	0.02 in	Expandable	Yellow	160 °C	-170 °C	Aramid Halogen Free

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 122.93

General part information

Sleeve X 25.00' (7.62m) Yellow

Technical documentation and resources
