AM10CW-480524DVZ

Obsolete

aimtec

DC DC CONVERTER 5V 24V 10W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM10CW-480524DVZ

Obsolete

aimtec

DC DC CONVERTER 5V 24V 10W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AM10CW-480524DVZ

Applications	ITE (Commercial)
Current - Output (Max)	1 A
Current - Output (Max)	209 mA
Efficiency	84 %
Features	Remote On/Off
Mounting Type	Through Hole
Number of Outputs	2
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	7-DIP Module
Power (Watts)	10 W
Size / Dimension [x]	25.4 mm
Size / Dimension [x]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [z]	0.46 in
Size / Dimension [z]	11.7 mm
Type	Isolated Module
Voltage - Input (Max) [Max]	75 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	1.5 kV
Voltage - Output 1 [Max]	24 V
Voltage - Output 1 [Min]	5 V
Voltage - Output 2	24 V

AM10C Series

Part	Current - Output (Max)	Current - Output (Max)	Voltage - Isolation	Voltage - Input (Max) [Max]	Mounting Type	Type	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]	Voltage - Output 2	Power (Watts)	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Applications	Voltage - Input (Min) [Min]	Features	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Approval Agency	Efficiency	Current - Output (Max) [Max]	Voltage - Output 1	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Package / Case	Current - Output (Max)
aimtec AM10CW-4812D-NZ	410 mA	410 mA	1.5 kV	75 V	Through Hole	Isolated Module	12 V	-12 V	-12 V	10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	18 V	Remote On/Off	85 °C	-40 °C	2	CE cURus UL	87 %
aimtec AM10CW-2405S-NZ			1.5 kV	36 V	Through Hole	Isolated Module				10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	9 V	Remote On/Off	85 °C	-40 °C	1	CE cURus UL	83 %	2 A	5 V
aimtec AM10CW-4815S-NZ			1.5 kV	75 V	Through Hole	Isolated Module				10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	18 V	Remote On/Off	85 °C	-40 °C	1	CE cURus UL	87 %	660 mA	15 V
aimtec AM10C-2405S-NZ			1.5 kV	36 V	Through Hole	Isolated Module				10 W	25.4 mm	10.2 mm			25.4 mm		ITE (Commercial)	18 V	Remote On/Off	85 °C	-40 °C	1		83 %	2 A	5 V	0.4 "	25.4 mm	1 in
aimtec AM10CW-2412S-NZ			1.5 kV	36 V	Through Hole	Isolated Module				10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	9 V	Remote On/Off	85 °C	-40 °C	1	CE cURus UL	87 %	830 mA	12 V
aimtec AM10CW-480512DVZ	417 mA		1.5 kV	75 V	Through Hole	Isolated Module	12 V	5 V	12 V	10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	18 V	Remote On/Off	85 °C	-40 °C	2		84 %						7-DIP Module	1 A
aimtec AM10CW-4824S-NZ			1.5 kV	75 V	Through Hole	Isolated Module				10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	18 V	Remote On/Off	85 °C	-40 °C	1	CE cURus UL	88 %	410 mA	24 V
aimtec AM10CW-4812S-NZ			1.5 kV	75 V	Through Hole	Isolated Module				10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	18 V	Remote On/Off	85 °C	-40 °C	1	CE cURus UL	87 %	830 mA	12 V
aimtec AM10CW-480524DVZ	209 mA		1.5 kV	75 V	Through Hole	Isolated Module	24 V	5 V	24 V	10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	18 V	Remote On/Off	85 °C	-40 °C	2		84 %						7-DIP Module	1 A
aimtec AM10CW-2415S-NZ			1.5 kV	36 V	Through Hole	Isolated Module				10 W	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	ITE (Commercial)	9 V	Remote On/Off	85 °C	-40 °C	1	CE cURus UL	87 %	660 mA	15 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

AM10C Series

Isolated Module DC DC Converter 2 Output 5 ~ 24V 24V 1A, 209mA 18V - 75V Input
