RJHSEKP84

Active

Amphenol ICC (Commercial Products)

8P8C, VERTICAL, SHIELD WITH SIDE

Search across all available documentation for this part.

Active

Amphenol ICC (Commercial Products)

8P8C, VERTICAL, SHIELD WITH SIDE

Technical Specifications

Parameters and characteristics for this part

Specification	RJHSEKP84

Connector Type	Jack
Contact Finish	Gold
Contact Finish Thickness	0.76 Ám
Contact Finish Thickness	30 Áin
Contact Material	Phosphor Bronze
Housing Material	Thermoplastic
LED Color	Yellow, Green
Mounting Type	Through Hole, Panel Mount
Number of Ports	1
Number of Positions/Contacts	8p8c (RJ45, Ethernet)
Number of Rows	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-55 °C
Orientation	Vertical
Shielding	Shielded, EMI Finger
Tab Direction	User Selectable
Termination	Solder

Part	Termination	Contact Finish Thickness	Contact Finish Thickness	Tab Direction	Shielding	Number of Rows	Mounting Type	Housing Material	Number of Positions/Contacts	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Contact Finish	Orientation	Number of Ports	Contact Material	LED Color
Amphenol ICC (Commercial Products) RJHSEKP80	Solder	0.76 Ám	30 Áin	User Selectable	Shielded EMI Finger	1	Panel Mount Through Hole	Thermoplastic	8p8c (RJ45 Ethernet)	85 °C	-55 °C	Jack	Gold	Vertical	1	Phosphor Bronze	Does Not Contain LED
Amphenol ICC (Commercial Products) RJHSEKP84	Solder	0.76 Ám	30 Áin	User Selectable	Shielded EMI Finger	1	Panel Mount Through Hole	Thermoplastic	8p8c (RJ45 Ethernet)	85 °C	-55 °C	Jack	Gold	Vertical	1	Phosphor Bronze	Green Yellow

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1320	$ 1.66

General part information

Jack Modular Connector 8p8c (RJ45, Ethernet) Vertical Shielded, EMI Finger
