1274012
ActivePhoenix Contact
SBC 2.4GHZ 1 CORE 4GB/0GB RAM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1274012
ActivePhoenix Contact
SBC 2.4GHZ 1 CORE 4GB/0GB RAM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1274012 |
|---|---|
| Core Processor | Intel Celeron N3350 |
| Ethernet | RJ45, 10/100/1000 Mbps |
| Expansion Site/Bus | mSATA |
| Number of Cores | 1 |
| Operating Temperature [Max] | 50 °C |
| Operating Temperature [Min] | -5 °C |
| RAM Capacity/Installed | 4 GB, 0 GB |
| RS-232 (422, 485) | 1 |
| Size / Dimension [x] | 7.72 " |
| Size / Dimension [x] | 196.08 mm |
| Size / Dimension [y] | 134.11 mm |
| Size / Dimension [y] | 5.28 in |
| Storage Interface | mSATA, SSD |
| USB | USB 2.0 (1), USB 3.0 (2) |
| Video Outputs | HDMI |
| Watchdog Timer | False |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 1836.62 | |
Description
General part information
127401 Series
Single Board Computer 1 Core 4GB/0GB RAM Intel Celeron N3350
Documents
Technical documentation and resources
