FE3 3/4 BLACK SPL

Active

Sumitomo Electric Interconnect Products, Inc.

HEATSHRINK 3/4" BLACK FOOT

Search across all available documentation for this part.

Active

Sumitomo Electric Interconnect Products, Inc.

HEATSHRINK 3/4" BLACK FOOT

Technical Specifications

Parameters and characteristics for this part

Specification	FE3 3/4 BLACK SPL

Color	Black
Features	Fluid Resistant, Flame Retardant
Inner Diameter - Recovered [diameter]	0.375 in
Inner Diameter - Recovered [diameter]	9.53 mm
Length	Enter Number of Feet in Order Quantity
Material	Fluoroelastomer (FKM)
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-40 °C
Recovered Wall Thickness	1.07 mm
Recovered Wall Thickness	0.042 in
Shrink Temperature	120 °C
Shrinkage Ratio	2 to 1
Spool Size	91.4 m
Spool Size	300 ft
Type	Tubing, Flexible

Part	Length	Features	Material	Shrink Temperature	Recovered Wall Thickness	Recovered Wall Thickness	Operating Temperature [Max]	Operating Temperature [Min]	Spool Size	Spool Size	Shrinkage Ratio	Color	Inner Diameter - Recovered [diameter]	Inner Diameter - Recovered [diameter]	Type
Sumitomo Electric Interconnect Products, Inc. FE3 3/4 BLACK SPL	Enter Number of Feet in Order Quantity	Flame Retardant Fluid Resistant	Fluoroelastomer (FKM)	120 °C	1.07 mm	0.042 in	200 °C	-40 °C	91.4 m	300 ft	2 to 1	Black	0.375 in	9.53 mm	Tubing Flexible

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Heat Shrink Tubing, Flexible 0.750" (19.05mm) 2 to 1 Black Enter Number of Feet in Order Quantity
