EGG.00.654.ZZM
ActiveLEMO
CONTACT SOCKET 28-32AWG CRIMP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
EGG.00.654.ZZM
ActiveLEMO
CONTACT SOCKET 28-32AWG CRIMP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | EGG.00.654.ZZM |
|---|---|
| Contact Finish | Gold |
| Contact Material | Bronze |
| Contact Size | 0.5 mm |
| Contact Termination | Crimp |
| Contact Type | Socket |
| Type | Signal, Machined |
| Wire Gauge or Range - AWG [Max] | 32 AWG |
| Wire Gauge or Range - AWG [Min] | 28 AWG |
| Wire Gauge or Range - mm² [Max] | 0.09 mm² |
| Wire Gauge or Range - mm² [Min] | 0.04 mm² |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 2.63 | |
| 10 | $ 2.38 | |||
| 25 | $ 2.26 | |||
| 50 | $ 2.21 | |||
| 100 | $ 2.10 | |||
| 250 | $ 1.84 | |||
| 500 | $ 1.79 | |||
| 1000 | $ 1.52 | |||
| 2500 | $ 1.42 | |||
Description
General part information
EGG.00.654 Series
Socket Contact 28-32 AWG Size 0.5mm Crimp Gold
Documents
Technical documentation and resources
