SRR4011-1R5YL

Active

Bourns Inc.

INDUCTOR POWER SHIELDED WIREWOUND 1.5UH 30% 100KHZ 11Q-FACTOR FERRITE 2.3A 0.056OHM DCR T/R

Search across all available documentation for this part.

Active

Bourns Inc.

INDUCTOR POWER SHIELDED WIREWOUND 1.5UH 30% 100KHZ 11Q-FACTOR FERRITE 2.3A 0.056OHM DCR T/R

Technical Specifications

Parameters and characteristics for this part

Part	Mounting Type	Inductance Frequency - Test	Type	Current - Saturation (Isat)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Q @ Freq	Shielding	Package / Case	DC Resistance (DCR) [Max]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Operating Temperature [Max]	Operating Temperature [Min]	Material - Core	Frequency - Self Resonant	Tolerance	Current Rating (Amps)	Inductance
Bourns Inc. SRR4011-6R2YL	Surface Mount	100 kHz	Drum Core Wirewound	1 A	1.3 mm	0.051 in	7 7.96 MHz	Shielded	Nonstandard	195 mOhm	0.189 "	4.8 mm	4.8 mm	0.189 in	125 °C	-40 °C	Ferrite	51 MHz	30 %	1.2 A	6.2 µH
Bourns Inc. SRR4011-151YL	Surface Mount	100 kHz	Drum Core Wirewound	220 mA	1.3 mm	0.051 in	39 796 kHz	Shielded	Nonstandard	3.8 Ohm	0.189 "	4.8 mm	4.8 mm	0.189 in	125 °C	-40 °C	Ferrite	8 MHz	30 %	0.25 A	150 µH
Bourns Inc. SRR4011-150YL	Surface Mount	100 kHz	Drum Core Wirewound	700 mA	1.3 mm	0.051 in	2.52 MHz 11	Shielded	Nonstandard	400 mOhm	0.189 "	4.8 mm	4.8 mm	0.189 in	125 °C	-40 °C	Ferrite	33 MHz	30 %	900 mA	15 µH
Bourns Inc. SRR4011-470YL	Surface Mount	100 kHz	Drum Core Wirewound	400 mA	1.3 mm	0.051 in	2.52 MHz 10	Shielded	Nonstandard	1.25 Ohm	0.189 "	4.8 mm	4.8 mm	0.189 in	125 °C	-40 °C	Ferrite	18 MHz	30 %	480 mA	47 µH
Bourns Inc. SRR4011-1R5YL	Surface Mount	100 kHz	Drum Core Wirewound	2.1 A	1.3 mm	0.051 in	7.96 MHz 11	Shielded	Nonstandard	56 mOhm	0.189 "	4.8 mm	4.8 mm	0.189 in	125 °C	-40 °C	Ferrite	121 MHz	30 %		1.5 µH

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1200	$ 0.36
Newark	Each (Supplied on Cut Tape)	100	$ 0.62

General part information

1.5 µH Shielded Drum Core, Wirewound Inductor 2.3 A 56mOhm Max Nonstandard
