1085855

Active

SICK, Inc.

SENSOR RETROREFLECTIVE 3M NPN

Deep-Dive with AI

Search across all available documentation for this part.

1085855

Active

SICK, Inc.

SENSOR RETROREFLECTIVE 3M NPN

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	1085855

Connection Method	Connector, M12
Ingress Protection	IP67
Light Source	631 nm
Light Source	Red
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-40 °C
Output Configuration	NPN
Response Time	500 µs
Sensing Distance [Max]	118.11 in
Sensing Distance [Max]	3 m
Sensing Distance [Min]	100 mm
Sensing Distance [Min]	3.937 "
Sensing Method	Retroreflective
Voltage - Supply [Max]	30 VDC
Voltage - Supply [Min]	10 VDC

HL18T Series

Part	Light Source	Light Source	Operating Temperature [Max]	Operating Temperature [Min]	Ingress Protection	Sensing Method	Connection Method	Response Time	Output Configuration	Voltage - Supply [Max]	Voltage - Supply [Min]	Sensing Distance [Min]	Sensing Distance [Min]	Sensing Distance [Max]	Sensing Distance [Max]	Cable Length	Cable Length
SICK, Inc. HL18T-P4A3AB	631 nm	Red	70 °C	-40 °C	IP67	Retroreflective	Connector M12	500 µs	PNP	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m
SICK, Inc. 1074767	631 nm	Red	70 °C	-40 °C	IP67 IP69K	Retroreflective	Cable	500 µs	PNP	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m	78.74 in	2 m
SICK, Inc. 1083398	631 nm	Red	70 °C	-40 °C	IP67 IP69K	Retroreflective	Connector M12	500 µs	NPN	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m
SICK, Inc. 1071042	631 nm	Red	70 °C	-40 °C	IP67	Retroreflective	Cable	500 µs	PNP	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m	78.74 in	2 m
SICK, Inc. 1086095	631 nm	Red	70 °C	-40 °C	IP67	Retroreflective	Cable with Connector	500 µs	PNP	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m	39.37 in	100 cm
SICK, Inc. 1080597	631 nm	Red	70 °C	-40 °C	IP67 IP69K	Retroreflective	Connector M8	500 µs	PNP	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m
SICK, Inc. 1085855	631 nm	Red	70 °C	-40 °C	IP67	Retroreflective	Connector M12	500 µs	NPN	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m
SICK, Inc. 1080225	631 nm	Red	70 °C	-40 °C	IP67	Retroreflective	Connector M12	500 µs	NPN/PNP	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m
SICK, Inc. 1083397	631 nm	Red	70 °C	-40 °C	IP67	Retroreflective	Cable with Connector	500 µs	NPN	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m	5.906 in	150 mm
SICK, Inc. 1081806	631 nm	Red	70 °C	-40 °C	IP67	Retroreflective	Cable with Connector	500 µs	NPN	30 VDC	10 VDC	100 mm	3.937 "	118.11 in	3 m	5.906 in	150 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 168.16

Description

General part information

HL18T Series

Retroreflective Optical Sensor 3.937" ~ 118.110" (100mm ~ 3m) NPN

Documents

Technical documentation and resources

No documents available
