PWM-90-12DA

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

LED DRIVER CV AC/DC

Technical Specifications

Parameters and characteristics for this part

Part	Features	Dimming	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Termination Style	Efficiency	Type	Ratings	Voltage - Output	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Voltage - Input (Max) [Max]	Approval Agency	Mounting Type	Voltage - Isolation	Power (Watts)	Voltage - Input (Min) [Min]	Current - Output (Max) [Max]	Topology	Standard Number
MEAN WELL USA Inc. PWM-90-24	OCP OTP OVP SCP	Analog PWM	2.48 in	63 mm	171 mm	37.5 mm	1.48 "	6.73 in	Wire Leads	90.5 %	Constant Voltage	IP67	24 V	85 °C	-40 °C	1	305 VAC	CB CCC CE cURus ENEC	Chassis Mount	3750 V	90 W	90 VAC	3.75 A	AC DC Converter
MEAN WELL USA Inc. PWM-90-12DA	OCP OTP OVP SCP	Analog PWM	2.48 in	63 mm	171 mm	37.5 mm	1.48 "	6.73 in	Wire Leads	88 %	Constant Voltage	IP67	12 V	85 °C	-40 °C	1	305 VAC	CB CCC CE cURus EAC ENEC	Chassis Mount	3750 V	90 W	90 VAC	1.88 A	AC DC Converter	UL 8750
MEAN WELL USA Inc. PWM-90-36	OCP OTP OVP SCP	Analog PWM	2.48 in	63 mm	171 mm	37.5 mm	1.48 "	6.73 in	Wire Leads	90.5 %	Constant Voltage	IP67	36 V	85 °C	-40 °C	1	305 VAC	CB CCC CE cURus ENEC	Chassis Mount	3750 V	90 W	90 VAC	2.5 A	AC DC Converter

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1.88A 12V Constant Voltage LED Driver AC DC Converter Topology 1 Output
