DX1093/TR

Active

BULGIN LIMITED

LED PANEL MOUNT INDICATOR, RED, AMBER, GREEN, 2.4 V, 8 MM, 30 MA, 2.5 MCD, IP66

Search across all available documentation for this part.

Active

BULGIN LIMITED

LED PANEL MOUNT INDICATOR, RED, AMBER, GREEN, 2.4 V, 8 MM, 30 MA, 2.5 MCD, IP66

Technical Specifications

Parameters and characteristics for this part

Part	Current	Lamp Color	Lens Style	Termination Style	Panel Cutout Dimensions	Panel Cutout Dimensions	Voltage	Lens Size	Lens Size	Millicandela Rating [custom]	Millicandela Rating [custom]	Millicandela Rating [custom]	Panel Cutout Shape	Type	Millicandela Rating
BULGIN LIMITED DX1093/TR	30 mA 30 mA 30 mA	Amber Green Red	Round with Domed Top	PC Pin	8 mm	0.315 in	2.4 V 2.4 V 2.4 V	T-1 3/4	5 mm	2.5 mcd	2.5 mcd	2.5 mcd	Round	LED
BULGIN LIMITED DX1093/BL	30 mA	Blue	Round with Domed Top	PC Pin	8 mm	0.315 in	3.5 V	T-1 3/4	5 mm				Round	LED	21 mcd
BULGIN LIMITED DX1093/RD	30 mA	Red	Round with Domed Top	PC Pin	8 mm	0.315 in	2 V	T-1 3/4	5 mm				Round	LED	25 mcd

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator Amber, Green, Red 2.4V Amber, 2.4V Green, 2.4V Red 30mA Amber, 30mA Green, 30mA Red PC Pin

Technical documentation and resources
