B72214U2271K501
ActiveEPCOS - TDK Electronics
VARISTOR 430V 6KA DISC 14MM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
B72214U2271K501
ActiveEPCOS - TDK Electronics
VARISTOR 430V 6KA DISC 14MM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | B72214U2271K501 |
|---|---|
| Capacitance @ Frequency | 440 pF |
| Current - Surge | 6 kA |
| Energy | 110 J |
| Maximum AC Volts [Max] | 275 V |
| Maximum DC Volts [Max] | 350 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 14 mm |
| Package / Case | Disc |
| Varistor Voltage (Max) [Max] | 473 V |
| Varistor Voltage (Min) [Min] | 387 V |
| Varistor Voltage (Typ) | 430 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.91 | |
| 10 | $ 0.55 | |||
| 25 | $ 0.46 | |||
| 200 | $ 0.31 | |||
| 400 | $ 0.28 | |||
| 600 | $ 0.26 | |||
| 1000 | $ 0.24 | |||
| 2600 | $ 0.21 | |||
| 5000 | $ 0.19 | |||
Description
General part information
B72214U Series
430 V 6 kA Varistor 1 Circuit Through Hole Disc 14mm
Documents
Technical documentation and resources
