09300161230ML

Active

HARTING Technology Group

16B SURFACE MOUNT HOUSING, DOUBLE LEVER, LOW CONSTRUCTION, 1XPG21 W/ METAL LEVERS

Search across all available documentation for this part.

Active

HARTING Technology Group

16B SURFACE MOUNT HOUSING, DOUBLE LEVER, LOW CONSTRUCTION, 1XPG21 W/ METAL LEVERS

Technical Specifications

Parameters and characteristics for this part

Specification	09300161230ML

Connector Type	Base - Box Mount
Housing Color	Gray
Housing Finish	Powder Coated
Housing Material	Die Cast, Aluminum
Ingress Protection	IP65 - Dust Tight, Water Resistant
Lock Location	Locking Clip (2) on Base Bottom
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Size	16 B
Size / Dimension [x]	4.606 "
Size / Dimension [x]	117 mm
Size / Dimension [y]	2.244 "
Size / Dimension [y]	57 mm
Size / Dimension [z]	56 mm
Size / Dimension [z]	2.205 in
Style	Side Entry
Thread Size	PG21

Part	Ingress Protection	Operating Temperature [Max]	Operating Temperature [Min]	Style	Size	Thread Size	Lock Location	Housing Color	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Connector Type	Housing Finish	Housing Material	Features
HARTING Technology Group 09300161230ML	IP65 - Dust Tight Water Resistant	125 °C	-40 °C	Side Entry	16 B	PG21	Locking Clip (2) on Base Bottom	Gray	4.606 "	56 mm	117 mm	2.205 in	2.244 "	57 mm	Base - Box Mount	Powder Coated	Aluminum Die Cast
HARTING Technology Group 09300161211ML				Side Entry	16 B	PG21	Locking Clip (2) on Base Bottom		4.606 "	56 mm	117 mm	2.205 in	2.244 "	57 mm	Base - Box Mount
HARTING Technology Group 09300161290ML	IP65 - Dust Tight Water Resistant	125 °C	-40 °C	Side Entry	16 B	PG21	Locking Clip (1) on Base Bottom	Gray	4.606 "	56 mm	117 mm	2.205 in	2.244 "	57 mm	Base - Box Mount	Powder Coated	Aluminum Die Cast	Feed Through

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Base - Box Mount Connector Side Entry PG21 16B IP65 - Dust Tight, Water Resistant
