1SR154-400TE25A

Obsolete

Rohm Semiconductor

DIODE GEN PURP 400V 1A PMDS

Search across all available documentation for this part.

Obsolete

Rohm Semiconductor

DIODE GEN PURP 400V 1A PMDS

Technical Specifications

Parameters and characteristics for this part

Specification	1SR154-400TE25A

Current - Average Rectified (Io)	1 A
Current - Reverse Leakage @ Vr	10 µA
Mounting Type	Surface Mount
Operating Temperature - Junction	150 °C
Package / Case	DO-214AC, SMA
Speed	Standard Recovery >500ns
Speed	200 mA
Supplier Device Package	PMDS
Technology	Standard
Voltage - DC Reverse (Vr) (Max) [Max]	400 V
Voltage - Forward (Vf) (Max) @ If	1.1 V

Part	Current - Average Rectified (Io)	Package / Case	Voltage - Forward (Vf) (Max) @ If	Mounting Type	Supplier Device Package	Current - Reverse Leakage @ Vr	Speed	Speed	Operating Temperature - Junction	Technology	Voltage - DC Reverse (Vr) (Max) [Max]
Rohm Semiconductor 1SR154-400TE25A	1 A	DO-214AC SMA	1.1 V	Surface Mount	PMDS	10 µA	Standard Recovery >500ns	200 mA	150 °C	Standard	400 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Diode 400 V 1A Surface Mount PMDS

Technical documentation and resources

No documents available
