TWR-5/3000-15/500-D12A-C

Active

Murata Power Solutions Inc.

ISOLATED BOARD MOUNT DC/DC CONVERTER, ITE, 3 OUTPUT, 20 W, 5 V, 3 A, +/-15 V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Product Change Notice EN +1

TWR-5/3000-15/500-D12A-C

Active

Murata Power Solutions Inc.

ISOLATED BOARD MOUNT DC/DC CONVERTER, ITE, 3 OUTPUT, 20 W, 5 V, 3 A, +/-15 V

Deep-Dive with AI

DocumentsDatasheet Product Change Notice EN +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TWR-5/3000-15/500-D12A-C

Applications	ITE (Commercial)
Current - Output (Max)	3 A, 500 mA
Mounting Type	Through Hole
Number of Outputs	3
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Package / Case	8-DIP Module, 7 Leads
Power (Watts)	20 W
Size / Dimension [x]	50.8 mm
Size / Dimension [x]	2 in
Size / Dimension [y]	2 in
Size / Dimension [y]	50.8 mm
Size / Dimension [z]	0.45 "
Size / Dimension [z]	11.4 mm
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	9 V
Voltage - Isolation	1.5 kV
Voltage - Output 1	5 V
Voltage - Output 2	15 V
Voltage - Output 3	-15 V

TWR-5 Series

Part	Efficiency	Voltage - Input (Max) [Max]	Applications	Number of Outputs	Voltage - Output 1	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Input (Min) [Min]	Voltage - Output 3	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Current - Output (Max)	Current - Output (Max)	Current - Output (Max)	Voltage - Output 2	Package / Case	Voltage - Isolation	Type
Murata Power Solutions Inc. TWR-5/1000-12/210-D12A-C	84 %	18 V	ITE (Commercial)	3	5 V	25.4 mm	50.8 mm	0.38 in	9.7 mm	25.4 mm	2 in	9 V	-12 V	Through Hole	100 °C	-40 °C	10 W	210 mA	210 mA	1 A	12 V	7-DIP Module 6 Leads	1.5 kV	Isolated Module
Murata Power Solutions Inc. TWR-5/3000-15/500-D12A-C		36 V	ITE (Commercial)	3	5 V	50.8 mm	50.8 mm	0.45 "	11.4 mm	2 in	2 in	9 V	-15 V	Through Hole	100 °C	-40 °C	20 W			3 A 500 mA	15 V	8-DIP Module 7 Leads	1.5 kV	Isolated Module

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 106.72
		10	$ 103.08
		25	$ 100.66
		50	$ 97.02
		100	$ 94.75
Newark	Each	1	$ 118.87
		5	$ 116.98
		10	$ 115.09
		25	$ 112.57
		50	$ 108.78
		100	$ 106.42

Description

General part information

TWR-5 Series

The TWR-5/3000-15/500-D12A-C is a 3-output board-mount fully-isolated DC to DC Converter with outstanding long-term high-reliability. The TWR A-series 20W 2 x 2-inch device is distinguished by its unique "power-sharing" architecture. It delivers any combination of primary plus auxiliary power as long as the total output power does not exceed 20W. This feature enables designers to select a single device to fulfill any number of different requirements. Its design combines straightforward circuit topologies, the newest components, proven SMT-on-PCB construction methods and highly repeatable automatic-assembly techniques. The superior durability is substantiated by a rigorous in-house qualification program that includes HALT (Highly Accelerated Life Testing). These full-featured triples have non-latching output current limiting, input overvoltage shutdown, input reverse-polarity protection and output overvoltage clamping to protect both the power converters and their loads.
