SW-PB2-2EZ-A-L1A
ActiveAdam Tech
PLASTIC WATERPROOF SWITCH, LATCH
Deep-Dive with AI
Search across all available documentation for this part.
SW-PB2-2EZ-A-L1A
ActiveAdam Tech
PLASTIC WATERPROOF SWITCH, LATCH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SW-PB2-2EZ-A-L1A |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Round, Button |
| Circuit | SPDT |
| Color - Actuator/Cap | Silver |
| Current Rating (Amps) | 5 A |
| Ingress Protection | Waterproof |
| Mounting Type | Panel Mount, Front |
| Operating Temperature [Max] | 55 °C |
| Operating Temperature [Min] | -25 °C |
| Switch Function | On-On |
| Termination Style | Solder Lug |
| Type | Standard |
| Voltage Rating - AC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 6.18 | |
| 10 | $ 5.34 | |||
| 25 | $ 5.03 | |||
| 50 | $ 4.82 | |||
| 100 | $ 4.61 | |||
| 250 | $ 4.34 | |||
| 500 | $ 4.15 | |||
| 1000 | $ 3.97 | |||
Description
General part information
SW-PB2 Series
Pushbutton Switch SPDT Standard Panel Mount, Front
