23C21D-40ML5

Active

Rosenberger

CONN MINICOAX 8PORT RA 50OHM SMD

Search across all available documentation for this part.

Active

Rosenberger

CONN MINICOAX 8PORT RA 50OHM SMD

Technical Specifications

Parameters and characteristics for this part

Specification	23C21D-40ML5

Body Finish	Gold
Body Material	Brass
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Connector Style	Miniature Coaxial
Connector Type	Plug, Male Pin (4), Jack, Female Socket (4)
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Snap-On
Frequency - Max [Max]	20 GHz
Housing Color	Gold
Impedance	50 Ohms
Mating Cycles	500
Mounting Type	Through Hole, Surface Mount, Right Angle
Number of Ports	8
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Shield Termination	Solder
Voltage Rating	500 V

Part	Connector Type	Mating Cycles	Operating Temperature [Max]	Operating Temperature [Min]	Fastening Type	Mounting Type	Connector Style	Impedance	Body Material	Frequency - Max [Max]	Shield Termination	Body Finish	Contact Termination	Center Contact Plating	Center Contact Material	Housing Color	Voltage Rating	Dielectric Material	Number of Ports
Rosenberger 23C21D-40ML5	Jack Female Socket (4) Plug Male Pin (4)	500	125 °C	-40 °C	Snap-On	Surface Mount Right Angle Through Hole	Miniature Coaxial	50 Ohms	Brass	20 GHz	Solder	Gold	Solder	Gold	Beryllium Copper	Gold	500 V	Polytetrafluoroethylene (PTFE)	8

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Miniature Coaxial Connector Jack, Female Socket (4); Plug, Male Pin (4) 50 Ohms Surface Mount, Right Angle; Through Hole Solder
