NJG1801K75-TE1
ActiveNisshinbo Micro Devices Inc
IC RF SWITCH SPDT 6GHZ 6DFN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
NJG1801K75-TE1
ActiveNisshinbo Micro Devices Inc
IC RF SWITCH SPDT 6GHZ 6DFN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | NJG1801K75-TE1 |
|---|---|
| Circuit | SPDT |
| Frequency Range | 6 GHz |
| Impedance | 50 Ohms |
| Insertion Loss | 0.45 dB |
| Isolation | 28 dB |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| P1dB | 31 dBm |
| Package / Case | 6-XFDFN Exposed Pad |
| RF Type | 802.11a/b/g/n/ac |
| Supplier Device Package | 6-DFN (1x1) |
| Test Frequency | 2.5 GHz, 5.9 GHz |
| Voltage - Supply [Max] | 5 V |
| Voltage - Supply [Min] | 1.8 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 5000 | $ 0.30 | |
| Cut Tape (CT) | 1 | $ 0.83 | ||
| 10 | $ 0.73 | |||
| 25 | $ 0.69 | |||
| 100 | $ 0.56 | |||
| 250 | $ 0.52 | |||
| 500 | $ 0.44 | |||
| 1000 | $ 0.36 | |||
| 2500 | $ 0.32 | |||
| Digi-Reel® | 1 | $ 0.83 | ||
| 10 | $ 0.73 | |||
| 25 | $ 0.69 | |||
| 100 | $ 0.56 | |||
| 250 | $ 0.52 | |||
| 500 | $ 0.44 | |||
| 1000 | $ 0.36 | |||
| 2500 | $ 0.32 | |||
| Tape & Reel (TR) | 5000 | $ 0.30 | ||
| 10000 | $ 0.29 | |||
| 25000 | $ 0.28 | |||
Description
General part information
NJG1801 Series
RF Switch IC 802.11a/b/g/n/ac SPDT 50Ohm 6-DFN (1x1)
