SDE0805A-150M
ActiveBourns Inc.
SURFACE MOUNT POWER INDUCTOR, AEC-Q200 SDE0805A SERIES, 15 H, 20%, UNSHIELDED, 0.09 OHM, 2.5 A
Deep-Dive with AI
Search across all available documentation for this part.
SDE0805A-150M
ActiveBourns Inc.
SURFACE MOUNT POWER INDUCTOR, AEC-Q200 SDE0805A SERIES, 15 H, 20%, UNSHIELDED, 0.09 OHM, 2.5 A
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SDE0805A-150M |
|---|---|
| Current - Saturation (Isat) | 2.2 A |
| Current Rating (Amps) | 2.5 A |
| DC Resistance (DCR) [Max] | 90 mOhm |
| Frequency - Self Resonant | 22.5 MHz |
| Height - Seated (Max) [Max] | 0.217 in |
| Height - Seated (Max) [Max] | 5.5 mm |
| Inductance | 15 µH |
| Inductance Frequency - Test | 1 MHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Unshielded |
| Size / Dimension [x] | 0.307 in |
| Size / Dimension [x] | 7.8 mm |
| Size / Dimension [y] | 0.276 in |
| Size / Dimension [y] | 7 mm |
| Tolerance | 20 % |
| Type | Wirewound, Drum Core |
SDE0805A Series
| Part | DC Resistance (DCR) [Max] | Frequency - Self Resonant | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Mounting Type | Current - Saturation (Isat) | Material - Core | Type | Ratings | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Inductance | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Shielding | Package / Case | Tolerance | DC Resistance (DCR) | Inductance Frequency - Test |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Bourns Inc. | 1.2 Ohm | 4.9 MHz | 0.217 in | 5.5 mm | Surface Mount | 500 mA | Ferrite | Drum Core Wirewound | AEC-Q200 | 650 mA | 125 °C | -40 °C | 330 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 10 % | ||
Bourns Inc. | 16.5 MHz | 0.217 in | 5.5 mm | Surface Mount | 1.8 A | Ferrite | Drum Core Wirewound | AEC-Q200 | 2.35 A | 125 °C | -40 °C | 22 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 20 % | 110 mOhm | 1 MHz | |
Bourns Inc. | 1.11 Ohm | 5 MHz | 0.217 in | 5.5 mm | Surface Mount | 550 mA | Ferrite | Drum Core Wirewound | AEC-Q200 | 700 mA | 125 °C | -40 °C | 270 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 10 % | ||
Bourns Inc. | 240 mOhm | 11.5 MHz | 0.217 in | 5.5 mm | Surface Mount | 1.2 A | Ferrite | Drum Core Wirewound | AEC-Q200 | 1.6 A | 125 °C | -40 °C | 56 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 10 % | 1 MHz | |
Bourns Inc. | 70 mOhm | 27.5 MHz | 0.217 in | 5.5 mm | Surface Mount | 2.6 A | Ferrite | Drum Core Wirewound | AEC-Q200 | 3.2 A | 125 °C | -40 °C | 10 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 20 % | 1 MHz | |
Bourns Inc. | 130 mOhm | 13.2 MHz | 0.217 in | 5.5 mm | Surface Mount | 1.6 A | Ferrite | Drum Core Wirewound | AEC-Q200 | 2 A | 125 °C | -40 °C | 33 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 20 % | 1 MHz | |
Bourns Inc. | 43 mOhm | 34.9 MHz | 0.217 in | 5.5 mm | Surface Mount | 3.7 A | Ferrite | Drum Core Wirewound | AEC-Q200 | 4 A | 125 °C | -40 °C | 5.6 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 20 % | 1 MHz | |
Bourns Inc. | 90 mOhm | 22.5 MHz | 0.217 in | 5.5 mm | Surface Mount | 2.2 A | Ferrite | Drum Core Wirewound | AEC-Q200 | 2.5 A | 125 °C | -40 °C | 15 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 20 % | 1 MHz | |
Bourns Inc. | 710 mOhm | 6.2 MHz | 0.217 in | 5.5 mm | Surface Mount | 650 mA | Ferrite | Drum Core Wirewound | AEC-Q200 | 0.85 A | 125 °C | -40 °C | 180 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 10 % | ||
Bourns Inc. | 71.2 MHz | 0.217 in | 5.5 mm | Surface Mount | 5 A | Ferrite | Drum Core Wirewound | AEC-Q200 | 5 A | 125 °C | -40 °C | 2.5 µH | 0.276 in | 0.307 in | 7 mm | 7.8 mm | Unshielded | Nonstandard | 20 % | 27 mOhm | 1 MHz |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.65 | |
| 10 | $ 0.51 | |||
| 25 | $ 0.46 | |||
| 50 | $ 0.42 | |||
| 100 | $ 0.39 | |||
| 250 | $ 0.35 | |||
| 500 | $ 0.33 | |||
| Digi-Reel® | 1 | $ 0.65 | ||
| 10 | $ 0.51 | |||
| 25 | $ 0.46 | |||
| 50 | $ 0.42 | |||
| 100 | $ 0.39 | |||
| 250 | $ 0.35 | |||
| 500 | $ 0.33 | |||
| Tape & Reel (TR) | 1000 | $ 0.30 | ||
| 3000 | $ 0.29 | |||
| 5000 | $ 0.28 | |||
| 10000 | $ 0.27 | |||
| 25000 | $ 0.26 | |||
| Newark | Each (Supplied on Full Reel) | 1 | $ 0.33 | |
| 5000 | $ 0.32 | |||
| 10000 | $ 0.30 | |||
| 20000 | $ 0.28 | |||
| 30000 | $ 0.26 | |||
| 50000 | $ 0.25 | |||
Description
General part information
SDE0805A Series
15 µH Unshielded Drum Core, Wirewound Inductor 2.5 A 90mOhm Max Nonstandard
