H8500XBBBR-A-B
ActiveBULGIN LIMITED
SWITCH ROCKER ON OFF SPST QUICK CONNECT CURVED ROCKER 15A 277VAC 372.85VA
Deep-Dive with AI
Search across all available documentation for this part.
H8500XBBBR-A-B
ActiveBULGIN LIMITED
SWITCH ROCKER ON OFF SPST QUICK CONNECT CURVED ROCKER 15A 277VAC 372.85VA
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | H8500XBBBR-A-B |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Concave (Curved) |
| Approval Agency | CSA, UL |
| Circuit | SPST |
| Color - Actuator/Cap | Black, Red |
| Current Rating (Amps) | 15 A |
| Features | Antimicrobial, Two-Tone Rocker |
| Mounting Type | Panel Mount, Snap-In |
| Panel Cutout Dimensions [x] | 19.3 mm |
| Panel Cutout Dimensions [y] | 12.9 mm |
| Switch Function | On-Off |
| Termination Style | Quick Connect - 0.187" (4.7mm) |
| Voltage Rating - AC | 250 V |
H8500XB Series
| Part | Voltage Rating - AC | Mounting Type | Approval Agency | Features | Actuator Marking | Circuit | Switch Function | Actuator Type | Termination Style | Current Rating (Amps) | Color - Actuator/Cap | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
BULGIN LIMITED | 250 V | Panel Mount Snap-In | CSA UL | Antimicrobial Two-Tone Rocker | No Marking | SPST | On-Off | Concave (Curved) | Quick Connect - 0.187" (4.7mm) | 15 A | Black Red | 19.3 mm | 12.9 mm |
BULGIN LIMITED | 250 V | Panel Mount Snap-In | CSA UL | SPST | On-Off | Concave (Curved) | Quick Connect - 0.187" (4.7mm) | 15 A |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 4.97 | |
| 10 | $ 4.43 | |||
| 25 | $ 4.20 | |||
Description
General part information
H8500XB Series
Rocker Switch SPST 15A (AC) 250 V Panel Mount, Snap-In
Documents
Technical documentation and resources
