LY T68B-U2V1-45-0-30-R18-Z-JC

Obsolete

ams-OSRAM USA INC.

LED YELLOW 2PLCC SMD

Deep-Dive with AI

Search across all available documentation for this part.

LY T68B-U2V1-45-0-30-R18-Z-JC

Obsolete

ams-OSRAM USA INC.

LED YELLOW 2PLCC SMD

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	LY T68B-U2V1-45-0-30-R18-Z-JC

Color	Yellow
Configuration	Standard
Height (Max) [Max] [z]	2.1 mm
Mounting Type	Surface Mount
Package / Case	2-PLCC
Size / Dimension [x]	3.2 mm
Size / Dimension [y]	2.8 mm
Supplier Device Package	2-PLCC
Viewing Angle	120 °

LY T68B Series

Part	Mounting Type	Color	Lens Color	Supplier Device Package	Wavelength - Dominant	Voltage - Forward (Vf) (Typ)	Wavelength - Peak	Millicandela Rating	Current - Test	Height (Max) [Max] [z]	Viewing Angle	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Lens Transparency	Lens Size [diameter]	Configuration
ams-OSRAM USA INC. LY T68B-U1V1-4-0-30-R18-Z	Surface Mount	Yellow	Colorless	2-PLCC	588 nm	2.1 V	594 nm	627 mcd	30 mA	2.1 mm	120 °	2-PLCC	1.3 mm	3.2 mm	Clear	2.4 mm
ams-OSRAM USA INC. LY T68B-U1V1-45-0-30-R18-Z	Surface Mount	Yellow	Colorless	2-PLCC	589 nm	2.1 V	594 nm	627 mcd	30 mA	2.1 mm	120 °	2-PLCC	1.3 mm	3.2 mm	Clear	2.4 mm
ams-OSRAM USA INC. LY T68B-T2V1-34-0-30-R18-Z-SV	Surface Mount	Yellow	Colorless	2-PLCC	586 nm	2.1 V	594 nm	627.5 mcd	30 mA	2.1 mm	120 °	2-PLCC	1.3 mm	3.2 mm	Clear	2.4 mm
ams-OSRAM USA INC. LY T68B-T2V1-26-0-30-R18-Z-SV	Surface Mount	Yellow	Colorless	2-PLCC	587 nm	2.1 V	594 nm	627.5 mcd	30 mA	2.1 mm	120 °	2-PLCC	2.8 mm	3.2 mm	Clear	2.4 mm	Standard
ams-OSRAM USA INC. LY T68B-T2-45-0-30-R18-XX	Surface Mount	Yellow	Colorless	2-PLCC	589 nm	2.1 V	594 nm		30 mA	2.1 mm	120 °	2-PLCC	1.3 mm	3.2 mm	Clear	2.4 mm
ams-OSRAM USA INC. LY T68B-T2V1-46-0-30-R33-Z-JC	Surface Mount	Yellow	Colorless	2-PLCC	591 nm	2.1 V	594 nm	627.5 mcd	30 mA	2.1 mm	120 °	2-PLCC	1.3 mm	3.2 mm	Clear	2.4 mm
ams-OSRAM USA INC. LY T68B-U2V1-45-0-30-R18-Z-JC	Surface Mount	Yellow		2-PLCC						2.1 mm	120 °	2-PLCC	2.8 mm	3.2 mm			Standard
ams-OSRAM USA INC. LY T68B-U1V1-34-0-30-R33-Z	Surface Mount	Yellow		2-PLCC						2.1 mm	120 °	2-PLCC	2.8 mm	3.2 mm			Standard
ams-OSRAM USA INC. LY T68B-U1V1-56-0-30-R18-Z-F	Surface Mount	Yellow	Colorless	2-PLCC	592 nm	2.1 V	594 nm	627 mcd	30 mA	2.1 mm	120 °	2-PLCC	1.3 mm	3.2 mm	Clear	2.4 mm
ams-OSRAM USA INC. LY T68B-T2U2-26-0-30-R18-Z-KS	Surface Mount	Yellow	Colorless	2-PLCC	588 nm	2.1 V	594 nm	532.5 mcd	30 mA	2.1 mm	120 °	2-PLCC	1.3 mm	3.2 mm	Clear	2.4 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

LY T68B Series

Yellow LED Indication - Discrete 2-PLCC

Documents

Technical documentation and resources

No documents available
